    Stainless Steel Water Slot Automatic CNC Wood Carving Machine 1.5kw Easy To Operate

    Ask Lasest Price
    Brand Name : Perfect Laser
    Model Number : PEM-2030
    Certification : CE / ISO / FDA / SGS / TUV
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 5000Units Per Year
    Delivery Time : 10-15working day
    • Product Details
    • Company Profile

    Stainless Steel Water Slot Automatic CNC Wood Carving Machine 1.5kw Easy To Operate

    Stainless Steel Water Slot Automatic CNC Wood Carving Machine

    (Model:PEM-2030)


    Introduction of cnc wood carving machine


    This engraving machine is mainly used for woodworking CNC engraving machine. It has a large working area and reaches 2000 * 3000 mm water-cooled circulating spindle. It is suitable for long-time processing, spindle protection cover, ensuring the environment of the spindle and the spindle power is optional. The engraving speed is fast, up to 4,000-7,000mm per minute. It also adopts imported linear square guide rails and double row and four rows of ball slides. It has large bearing capacity, stable operation, high precision and long service life. This woodworking CNC engraving machine can be equipped with embedded DSP or CNC professional CNC machining system. When the power is off, the woodcarving CNC machine can continue to engrave, the machining time can be predicted, and the tool (optional) can be simulated.


    Features of cnc wood carving machine


    1. Easy to operate, handle-operated, large LCD screen, unique design.

    2. Compatible with a variety of software, such as TYPE3, ARTCAM, JD engraving, MasterCAM, UG, Castmate CAD / CAM software for various industrial designs.

    3. According to the processing requirements, the spindle power can be selected up to 4.5KW.

    4. XYZ axis transmission, X and Y axis rack drive, fast speed and high efficiency. Z-axis with precision ball screw for higher precision and durability.


    Application Range of cnc wood carving machine


    1.Wood cnc machine suitable materials: Wood, MDF, MDF, PVC plastic, plexiglass, acrylic and other non-metallic materials and common metal materials.

    2.Wood cnc machine suitable industry: advertising word engraving and cutting, MDF cutting and engraving, hibiscus board processing, acrylic processing, handicrafts, signs, nameplate, electronic chassis openings, small cylindrical three-dimensional relief, PVC cutting and so on.


    Technical Data of cnc wood carving machine


    ProductAdvertising CNC Router
    ModelPEM-2030 (2000*3000mm)
    Power2.2kw3kw4.5kw
    Table materialAluminum Alloy
    Maximum feed height80mm
    X,Y,Z Guideway rails typeRound Shape Guide Rail, Rod Transmission
    Max Engraving Speed4,000-7,000mm/min
    Resolution ratio0.002mm
    Repetition accuracy±0.02mm
    Spindle power1.5kw (Optional 2.2kw, 3kw,4.5kw)
    Spindle Rotating Speed6000 - 24,000rpm
    Spindle coolingWater Cooling
    Drive motor systemStep Motor and Step Driver
    InterfacePCI Port or USB Port
    Memory buffer (Flash)128MB
    Engraving CommandG code, u00, mmg, PLT, HPG
    Command language systemEnglish Version, Windows 98/2000/XP Operation System
    Operational SoftwareOriginal Type3 Software, ArtCam software or Wentai Software
    Software CompatibilitySupport CAD/CAM software, PLT format, Corel Draw, Auto CAD
    Working temperature0-45
    Relative humidity30% - 75%


    Samples of
    cnc wood carving machine



    Packaging & Delivery


    1. Prompt deliver at the very day.
    2. Well-trained and disciplined packing team.
    3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
    4. Sophisticated and professional logistic agent.


    ★Competitive Advantages


    1. 100% custom pass guaranteed.
    2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
    3. Flexible and Untraceable payment terms.
    4. Good after-sale service.
    5. We offer high quality products at competitive price in quick delivery.
