Pharmaceutical Fully Automatic Hard Capsule Filling Machine For
Powder Granule
Product Description of Capsule Filling Machine
SED-1200J-H Automatic Capsule Filling Machine is commonly used in
the pharmaceutical, nutraceutical industries to fill empty hard
gelatin capsule of various sizes with powders and pellets
(optional). The capsule filler automatically orientates, opens the
empty hard gelatin capsule, properly fills the capsule with powder,
and automatically closes the capsules.
Product Parameter of Capsule Filling Machine
| Model | SED-1200J-H |
| Capacity | 1200 capsules/min |
| Filling Material | Powder, Granules |
| Die Hole Number | 9 |
| Power Supply | 380V 50Hz 3P |
| Total Power | 5.57KW |
| Application | 00#-4# capsule |
| Filling Variation | ±3% - ±4% |
| Noise | ≤75dB(A) |
| Qualified Rate | ≥99.5% |
| Overall Dimension | 1020mm (L) x 860mm(W) x 1970mm(H) |
| Weight | 900kg |
Characteristic of Capsule Filling Machine
1. The split-type design of the capsule loading mechanism and the
patented fully-enclosed structure prevent the capsules from
improperly falling into the capsule transmission room and ensure
the capsules to perform smoothly.
2. The patented powder filling mechanism includes several patented
techniques like the irregular multi-surface powder keeper, the
lateral angled feeder, etc., which makes the powder evenly
distribute within the powder storage room, correctly and smoothly
flow into the capsules, and achieves an extremely precise capsule
filling process.
3. The patented modular punch as well as the bi-nodal feed hopper
is of simple dismounting and with accurate positioning.
4. The patented integrated rotary table with ultra-precision has
features like small size, light load, long service life, three
years free of oil and maintenance and so on.
5. The whole set of the molds and all the parts that need daily
cleaning and maintenance are equipped with locating pins, and the
connection as well as fastening among different parts is extremely
simple. As the fastening tool is standardized in size, a small
spanner can easily dismount all the parts.
6. All the connectors of the air pipes apply standardized clamps,
which are much easier to dismantle and clean than others.
Product Details
Application
