Material of the profile: 195-235Mpa GI or carbon steel
Thickness range: 0.8-3.0mm
Maximum production speed: not less than 18 meters per minute (for
non-perforated profiles, excluding cutting)
Main motor power:60kw, AC motor, motor inside of main machine
(Brand: Guomao of China)
Machine Voltage, Frequency, Phase: 380 V, 50 Hz, 3Phase
Roll station:20 stations
Roller material:Gcr15 bearing material chrome plated surface with
hardness 58-62 degree ,CNC,
Shaft diameter: ￠150mm material: SAE1045 with quenching and
tempering
Transmission: by gear box 200*500(outside is cast iron, surface
needed polish and paint. Inside is 60# forge and press metal)
Technique Data
1. Material: galvanized coils
2. Material Thickness: 1.5-3.5mm
3. Forming Station: 18
4. Rolling Machine Working Speed: 12-15m/min
5. Drive System: gear box drive
6. Main motor power: 90Kw
7. Punching mold: 3 sets of punching dies at one time
8. Cutting: hydraulic cutting
9. Hydraulic Power: 55Kw, the pressure 25-30Mpa
10. Total Power: 130Kw
11. Out Table: lift auto stacker
Machine Components
| S.N. | Machine List | Qty |
| 1. | 10 ton hydraulic decoiler | 1 set |
| 2. | Feeding&leveling device | 1 set |
| 3. | Gear box drive system | 1 set |
| 4. | Main forming machine | 1 set |
| 5. | Curving device | 1 set |
| 6. | Hydraulic cutting device | 1 set |
| 7. | Auto stacker 6 meters | 1 set |
| 8. | PLC control system | 1 set |
| 9. | Hydraulic station | 1 set |
Advantage of roll forming machine
1 . Reasonable Price
2 . High Quality
3 . 12 Months Warranty
4 . More Than 10 Years Experience
5 . Durable
6 . Reliable
Working Flow of production line
Decoiler--Feedingwithguide--Straighteningdevice--Mainrollformingmachine--Curving--Outputtable
