| Brand Name : | KACISE |
| Model Number : | KUS-M56 |
| Certification : | CE |
| Price : | USD129 to USD158 per pc |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 1000 Piece/Pieces per Week negotiable |
| Delivery Time : | 5-8 work days |
High resolution
Short response time
Digital tube display measuring distance
Various springs available: switch, analog, or RS232/485
Range | 0.1~0.5m,0.15~1m,0.3~3m,0.4~5m,0.5~6m |
Resolution | 3mm or 0.1%(which is bigger) |
Response time | < 200ms |
| Display | LED |
| Emission angle | 20°C |
| Analog output | 4~20mA/500Ω LOADING |
| Switch output | PNP/NPN(optional) |
| RS232/485 | MODBUS protocol or customized protocol (optional) |
| Power supply | Standard 24VDC (±15%) |
| Ambient temperature | -20~+60℃ |
| Protection Class | IP65 (IP66 is optional) |
| Installation | M56*2 |
| Note: Only one output can be chose among the three kinds of outputs. | |
5.2 Ultrasonic sensor installation dimensions


|
