    Annealed Bare Copper Single Core Special Power Cable TFL Power Cables

    Ask Lasest Price
    Brand Name : CN cable
    Model Number : TFL
    Certification : CE
    Payment Terms : L/C, T/T
    Delivery Time : 20 days after payment
    • Product Details
    • Company Profile

    Annealed Bare Copper Single Core Special Power Cable TFL Power Cables

    Use for communication stranded annealed bare copper single core TFL power cable


    Application

    Flexible, halogen free cable for connection of back-up batteries, central office power distribution or grounding.

    Conductor

    Stranded, annealed bare copper, flexible according to IEC 60228 class 5.

    Insulation

    Flame retardant TPE, black

    Jacket

    Flame retardant TPE, grey

    Approvals

    UL-listed, “Cable Tray Use”

    Operating voltage

    0,6 / 1kV

    Operating temperature

    Max 90 ºC

    Fire resistance

    IEC 60332-3 cat C UL 1685, Vertical Tray Flame Test


    Technical Data

    Conductors x sizeDiameter, nom. (mm)Weight/100mResistance
    ConductorInsulationJacket(kg)(W/km)
    1 x 25mm² (4 AWG)7,210,012,8350,780
    1 x 35mm² (2 AWG)7,810,613,4450,554
    1 x 50mm² (1 AWG)9,512,315,1600,386
    1 x 70mm² (2/0 AWG)11,013,816,7770,272
    1 x 95mm² (3/0 AWG)12,515,718,91020,206
    1 x 150mm² (250 kcmil)16,520,123,31550,129
    1 x 300mm² (500 kcmil)23,027,931,83130,064

    Ordering Information

    Conductors x sizeLengthTotal weight
    (m)(kg)
    1 x 25mm² (4 AWG)500200
    1 x 35mm² (2 AWG)500250
    1 x 50mm² (1 AWG)500324
    1 x 70mm² (2/0 AWG)500413
    1 x 95mm² (3/0 AWG)500593
    1 x 150mm² (250 kcmil)240402
    1 x 300mm² (500 kcmil)250898
