MIAMI-DADE Country Approved Coil Roofing Nails,RING SHANK High
Quality
Product Description
As we know, Florida receives some of the harshest weather in the
world. High winds, when coupled with corrosive salt water, can lead
to extremely detrimental product failures.
Low quality "EG" nails quickly rust when exposed to salt water. Our
double electrical galvanized nails are dipped twice into molten
zinc, giving them an unparalleled corrosion-resistant coating.
Specification 0f Roofing Coil Nails
Material: Steel Q195
Head Diameter: 5.0--8.0mm
Head Thickness: 1.00-0.1mm
Shank Type: Smooth/ Screw/ Ring
Shank Diameter: .120''
Welding Position: 8-19mm/19-37mm/19-52mm
Point Type: Diamond /Blunt /Chisel
Finish: Bright/Yellow Painting/E G/H.D.G/M.G/ Stainless steel
ASTM F 1667
| Property | Test Method | Result | Requirement |
| Physical Properties | | | |
| Ductility,0.125"Mandrel | ASTM F 680 | Pass | Pass |
| Tensile Strength | ASTM F 680 | NOT tested | Not Required |
| Dimensions and Tolerances | | | |
| Length,overall,in | ASTM F 680 | 1.25 | Report |
| Diameter,at thread crest,in | ASTM F 680 | 0.124 | Report |
| Length tolerance,in | ASTM F 680 | <1/64 | ±1/16 |
| Shank diameter tolerance,in | ASTM F 680 | 0.001 | ±0.004 |
| Head diameter tolerance,%(power driven) | ASTM F 680 | 3 | Report |
| Zinc Coating | | | |
| Coating Process | ASTM F 1667 | Electrogalvanized | Hot dip or electrogalvanized |
| Coating amount,after forming,oz/ft³ | ASTM A 90 | 0.31 | ≥0.28 |
| Other | | | |
| Workmanship | ASTM F 680 | Pass | Free from imperfection,dean,freee of corrosion |
| Altered Nail Shapes and Deformations | ASTM F 1667 | Annular Ring | Annular Ring |
TAS 114 APPENDIX E
| Property | Test Method | Specimen NO. | Result | Requirement |
| Corrosion Resistance,(% of surface area)After 140 cycles | ASTM G85/TAS 114 App.E/ASTM D 610 | 1 2 3 4 5 6 7 8 9 10 | 0 0 0 0 0 0 0 0 0 0 | ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 |
Statement of Compliance:
The product was tested in accordance with ASTM F 1667-15 Standard
Specication For Driven Fasteners:Nails,
Spikes,and Staples and Miami-Dade Country Checklist #0195 for the
certification and listing of roofing fasteners,The product
demonstrated compliance with ASTM F 1667 for a ring shank roofing
nail,and met the requirements for corrosion resistance
after 140 cycles of TAS 114 Appendix E.
