    Magjacc SMT RJ45 Jack Module / Surface Mount Rj45 Plug TM56S011EXX45

    Ask Lasest Price
    Brand Name : TM
    Model Number : TM56S011EXX45
    Certification : UL,Rohs,Reach,ISO9001
    Price : Supportive
    Payment Terms : T/T, Western Union, ,Paypal
    Supply Ability : 500K/year
    Delivery Time : 20Days
    • Product Details
    • Company Profile

    Magjacc SMT RJ45 Jack Module / Surface Mount Rj45 Plug TM56S011EXX45

    SMT 1x1 Port RJ45 Magjack low profile ethernet connector Without Magnetics TM56S011EXX45

    Materials:


    Housing : FR52,UL94V-0 ( RoHS )
    Contact Finish: T=0.35 mm GOLD PLATING 6U" OVER NICKEL IN CONTACT TIN PLATING OVER NICKEL IN SOLDER AREA.( RoHS )
    Shielding Shell: 0.20mm THICKNESS COPPER ALLOY WITH NICKEL PLATED.
    All materials mates with modulat plug conforming to FCC part 68. subpart F.


    Product Structure:


    RJ45 Jack
    1 x 1 Port / Single Port / SMT Port
    Latch Down
    Connector Length: 18.65 mm
    Connector Width: 15.74 mm
    Connector Height: 11.75 mm
    Termimal Solder Pin Length: 2.5 mm
    10P10C ( 10 positions 10 contacts )
    90°Orientation
    Without, let know the connection status
    With Shield,can be customized as required
    We Support Custom service as required


    RJ45 Without Transformer (TM56S011EXX45) Attributes:


    Model:TM56S011EXX45
    Place of Origin:Guangdong of China
    Certification:UL,Rohs,Reach,ISO9001
    Product Type :RJ50 Modular Connector
    Jack Type:RJ50
    Number of Positions :10
    Terminals per Port:10
    LED Option:No
    Shielded EMI Tabs:No
    Voltage rating:125 V
    Current rating:1.5 A
    Contact resistance:30mΩ
    Insulation resistance:500 MIN @ 500V DC
    Dielectric resistance:1000V AC RMS 50Hz. 1MIN
    Durrability:750 CYCLES MIN
    Minimal Order:1pcs
    Package:120pcs/tray,1440pcs/carton
    Carton size:33*33*21cm
    Delivery Time:20 Days
    Supply Ability:5KK/year

    RJ45 Female Connector (TM56S011EXX45) Mechnical Drawing:
