    1500L Mirror Polished 3 Vessel Brewhouse With PLC Control

    Ask Lasest Price
    Brand Name : YDL/OEM
    Model Number : YDL
    Certification : ISO,CE,TUV
    Price : Negotiation
    Payment Terms : L/C, T/T, D/P
    Supply Ability : 150 Set / Month
    Delivery Time : Within 30 - 60 Days
    • Product Details
    • Company Profile

    1500L Mirror Polished 3 Vessel Brewhouse With PLC Control

    1500L Mirror Polish Three Vessel Brewhouse With 50mm PU Insulation And Plc Control


    Description:

    Brewhouse have all the components which are necessary to brew beer, from malt mill, Mash tun/Lauter tun, Kettle/Whirlpool tank, heat exchanger, pumps, working table to pipelines. Vessel height& diameter depends on the ceiling height and brewer s habits and brewing capacity, beer types.

    According to brewing capacity, micro brew house have mainly 3 types of combo depending on vessel numbers,

    2- Vessel Brewhouse

    Mash/Lauter Tun/ + Brew Kettle/Whirlpool

    Mash/ Brew Kettle/Whirlpool+ Lauter Tun

    3- Vessel Brewhouse

    Mash/Lauter Tun + Brew Kettle + Whirlpool

    Mash Tun+ Lauter Tun + Brew Kettle/Whirlpool

    4- Vessel Brewhouse

    Mash Tun + Lauter Tun + Brew Kettle + Whirlpool

    Heating method for brewhouse can be direct fire, steam/gas or electricity, it makes different design and specifications of vessels, e.g. fire box would be adopted when the vessel is heated by direct fire.

    According to client s budget and requirements, the brewhouse system can be controlled by manual, automatic or half-automatic.

    We d like to custom and produce brewhouse for different clients coming from restaurant, brewpub or microbreweries, if needed we can also help to install and commission the system.




    Configurations:

    - Material: SS304

    - Finish: brushed external, polished internal less than 0.6um,

    - Dished top, flat bottom, 4 legs with leveling feet,

    - Bottom agitator,0.55kw, 36RPM, VFD control

    - Insulation 60-80mm rock wool,

    - Cladding steel S/S304,

    - Removable false bottom,

    - Grain spent on the side,

    - Sparging arm

    - CIP,

    - Thermometer


    whouse System
    3 Vessels Brewhouse
    Mash/Lauter Tun1500L, 2.2KW/60HZ motor, Speed is 0~60 r/min by inverter
    Boil Kettle1500L
    Whirlpool Tun1500L
    Wort grant20L,Glass wort grant
    Plate Heat Exchanger18m2,2 stages
    Working PlatformDismountable,SS304
    Valves and Pipeline1 set
    Wort pump3T/hr,Sanitary SS304, Pump lift-24m
    Control System
    Selectable
    Manual
    Semi-Auto by PLC

    Advantages:

    1. Made by nice stainless steel 304,sanitary grade,

    2. All welded parts are polished smoothly,

    3. Interior cooling plate has better performance of heat exchanging,

    4. Reasonable prices


    Quality control

    ● All stainless steel coils are purchased from high-quality steel supplier.All chemical composition and mechanics performances are controlled strictly.

    ● All welders are qualified.

    ● ISO9001 system assures all procedures done correctly.

    ● All tanks are inspected completely before delivery, including hydrostatic test, dye penetration test,etc.

    Convenient logistics

    ● Door to door delivery saves time&energy for clients.

    ● Optimized container proposals save client’s shipping freight.

    ● Safe seaworthy package and loading guarantee non-destroyed parts during shipping is promised.

    After-sales Service Provided:

    2 yearS of tank and 6 months of accessories guarantee, lifelong maintenance at cost charge

    7x24 hours per week email&phone available

    Maintenance, return & exchanges services


    Package:

    Each tank is wrapped with blanket and anti-water film, lay down on steel saddle in the container,and is braced by steel wire.The packaging looks very beautiful and won’t be damaged during shipment
