    Hexagon Socket Head Shoulder Screw Stainless Steel DIN ISO JIS ANSI Standard

    Ask Lasest Price
    Brand Name : Runtai
    Model Number : Shoulder Screws
    Certification : ISO9001/TS16949
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram, D/A
    Supply Ability : 5 Ton/ days
    Delivery Time : 15-20 working days
    • Product Details
    • Company Profile

    Hexagon Socket Head Shoulder Screw Stainless Steel DIN ISO JIS ANSI Standard

    Stainless Steel Socket Head Shoulder Screws ISO7379 Hexagon Socket Head Wheel Bolts


    Products Description


    Made from 18-8 stainless steel, these shoulder screws have good chemical resistance and may be mildly magnetic. A standard shoulder with an undersized tolerance allows them to fit most machinery and equipment. They’re often used to guide or align components, and as an axle or pivot point.

    Products Specification

    Shoulder FitStandard
    Shoulder Diameter8 mm
    Shoulder Diameter Tolerance-0.072 to -0.01 mm
    Shoulder Length25 mm
    Shoulder Length Tolerance0 to 0.25 mm
    Thread SizeM6
    Thread Pitch1 mm
    Thread TypeMetric
    Thread SpacingCoarse
    Thread FitClass 5g6g
    Thread DirectionRight Hand
    Thread Length11 mm
    Head Diameter13 mm
    Head Height5.5 mm
    Material18-8 Stainless Steel
    HardnessRockwell B55
    Tensile Strength70,000 psi
    Minimum Shear Strength35,000 psi
    Head TypeSocket
    Socket Head ProfileStandard
    Head TextureKnurled
    Drive StyleHex
    Drive Size4 mm
    Specifications MetISO 7379
    System of MeasurementMetric
    RoHSCompliant

    Note: Material, Size and Surface Treatment for choose.
