Small Size Black Video Recorder 8 Channel HD 720P SD Card MDVR With GPS 4G

Ask Lasest Price
Brand Name :	Yoelbaer or OEM
Model Number :	YB-LSJ008
Certification :	CE ,FCC ,ROHS
Price :	Negotiable
Supply Ability :	2000sets/week
Delivery Time :	3-7 working days for mass order, samples have in stocks

Add to Cart

Product Details
Company Profile

Small Size Black Video Recorder 8 Channel HD 720P SD Card MDVR With GPS 4G

Small Size Black Video Recorder 8 Channel HD 720P SD Card MDVR With GPS 4G

Model	720P AHD 8CH MDVR
System
OS	Linux
Language	Chinese/English/Customized
Video
Video Input	4CH 720P AHD input, aviation connector, 1.0Vp-p, 75Ω
Video Output	1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen
Video Compression	H.264
Video Quality	1-4 levels, 1 is the highest level.
Video Standard	PAL: 100f/s , CCIR625 line,50field; NTSC: 120f/s, CCIR525 line,60field; CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional; HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional; D1: 800Kbps ~ 3Mbps, 8 level video quality optional; 720P: 4Mbps-6Mbps, multi level video quality optional
Audio
Audio Input	4CH ,Aviation Plug
Audio Output	1CH,Aviation Plug
Audio Compression	G.726 compression, 8KB/s speed
Display
OSD	Overlays information such as date time and vehicle ID
Preview	Support 1 channel and 4 channels preview, Support Manual /Alarm Trigger full screen preview
Graphical User Interface	Setup system parameters with the remote control.
Recording
Resolution	720P/D1/HD1/CIF, MAX:4 channels of 720P and 4 channels of D1
Record Mode	The default setting is auto recording after power on.Timed recording, Alarm trigger recording and manual recording are supported.
Alarm
Alarm Input	6Ch Alarm Input, kinds of alarm linkage support
Alarm Output	2CH Alarm Output
Playback
Search Mode	Search By Record Time/Record Type etc
Playback Speed	Max support 4CH Replay /Stop/Fast/Slow at same time Support forward and backward play at the speed of: x2, x4, x8, x16.
Network
123
Ethernet	RJ-45 port (10/100M)
3G/4G/WiFi	Optional
GPS	Built-in high accurate GPS module(optional)
G-Sensor	Support G-sensor
Storage
SD Card	Dual SD Card, each max 128GB SD Card loop recording
Auxiliary Interface
USB	1 Port , USB 2.0
RS485	1 Port, For PTZ control
RS232	2 Ports, For Temperature Sensor, Fuel Sensor etc.
General
Voltage Input	DC:+10V ~ +36V
Voltage Output	+12V@2.5A,+5V@2.5A
Power Consumption	Normal Working ＜5W
Power Management	Wide Voltage. Support Timed/Delay off
Temperature	-20℃ to +70℃
Humidity	20% to 80%

Key Specifications/Special Features:

Operation languages: English/Chinese/Traditional Chinese/other
Equipment parameters: graphical menu interface (OSD menu)
Password security: two-level management of user password and administrator password
Video input: 4CH composite video input
Video output: 1CH composite video output, 1ch VGA output
Video display: single-picture and quad-picture display
Video standard: PAL/NTSC
Image compression: H.264 main profile, compressed resource, 4ch 720P/1080P@25fps/30fps
Audio input: 4CH audio input
Audio output: 1CH audio output
Recording manner: synchronous recording of audio and video
Image format: 1080P/720P/CIF/HD1/D1, optional
Audio bit rate: 8KB/s
Data storage: supported 128GB SD card/2T hard disk
Alarm input: 4 alarm inputs, low-level alarm for less than 4V, high-level alarm for more than 4V
Alarm output: 1 alarm outputs, high-level output at 12V and 5V
Sensors: 1 speed sensor, 1 ignition sensor, 3 sensors for brake, return etc.
RS485 interface: supported 1 RS485 interface
RS232 interface: supported 1 RS232 interface
Network: RJ45,10M/100M
Wifi: 802.11/b/g/n (300Mbps)
3G/4G(WCDMA):For remote live view, data transfer, alarm report etc.
GPS:Support GPS receiver(optional), can record GPS information along with video and audio. GPS data format: NEMA0183, Baudrate: 4800bps
Acceleration sensor: built-in acceleration G-sensor
Software kit: play back the video file on PC and analyze the vehicle information in the file
Software upgrade: file via SD
Power input: 8-36V, input voltage between +8V and +36V, when the voltage is lower than 8V or higher than 36V for a long period of time, the equipment will shut down automatically and enter into protected mode
Power output: 12V, output voltage 12V (+/-0.2V), maximum current 2A
Car key signal ≤4V: car key on, ≥5V car key off
Video input resistance: 75Ω, video input resistance at each channel should be 75Ω
Video output voltage: 2Vp-p, for output of a 2Vp-p CVBS analog signal, the displayed input resistance shall be 75Ω
I/O interfaces: 0-4V low-level alarm
Over 4V: high-level alarm
