Advertising LED Screens P6 Outdoor Full Color Video IP65 for Rental
Usage
Indoor small pixel pitch screen:With the development of science and technology,
the cost of display screen is gradually reduced, and the demand for
small indoor spacing
is increasing year by year. No doubt, it has become the first
choice of more and more customers.
Outdoor rental series:This kind of product is very popular in our company,every year it
sells about 5000sqm quantity,
the customers are from all over the world,such as
America,England,India,Russia,South America...And we still make the
stable cooperation,for that we can provide them the high quality
product,also the price,but most important is the
good after-sales service.For it is different from other product,it
belongs to the item with long life cycles,so everybody
would worry about the warranty,if some problems appears,how to do?
Specifications :
| Outdoor P6 LED Display Screen |
| Resolution/mm | 6 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 27778/square meter |
| Module resolution | 32x32 |
| Module size/mm | 192x192 |
| View distance | 6-60m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >5500cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | >720Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test. Mixed samples are
acceptable.
Q2. What about the lead time?
A:Sample order needs 3-5 days, mass production time needs 1-2 weeks
for order quantity more than.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1sqm for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 8-20
days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our
suggestions.
Thirdly customer confirms the samples and places deposit for formal
order.
Fourthly We arrange the production.
Advantage
1. We have the advantage of a full range of LED display production
2: Goods supply from indoor and outdoor P10, P8, P6, P4,P3,P3.91,
P4.81, P2, P2.5, P1.976 have sufficient inventory, at the same time
has high quality, let you buy at ease, use at ease
3. We have round-the-clock online customers to help customers and
give customers product performance introduction, as
wellasproduct advantage analysis; According to the actual situation
and the use of the situation, for the customer
evaluation,choosethe most reasonable scheme
4: At the same time, we can provide customers with professional
training on the operation and maintenance of the led display
system Display troubleshooting
