Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm

    Buy cheap Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm from wholesalers

    Buy cheap Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm from wholesalers
    • Buy cheap Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm from wholesalers
    • Buy cheap Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm from wholesalers

    Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm

    Ask Lasest Price
    Brand Name : ZHECHUN
    Model Number : CZ01
    Payment Terms : T/T, L/C
    Supply Ability : 15,000,000 square meter per year
    Delivery Time : 10 days after deposit
    • Product Details
    • Company Profile

    Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm

    0.38mm PVB Laminating Film for construction glass

    PVB films, also called Polyvinyl Butyral, are extruded mixture of special plasticizer, additives and PVB resin that form PVB films with even thickness.


    PVB films are primarily applied in laminated glass that is a construction of two or more pieces of glass. The high adhesive PVB films are clamped between layers, so PVB films must equip with excellent adhesion, light transmission and safety.



    technical parameters


    No.Classfication
    ltems
    0.38mm0.76mm
    1Appearance
    1.1AppearancesAchromatic or slinghtly yellow lucid film With velvet surface that has no scar or crease .
    1.2Dotted waste sundries and air buhbles
    ≤0.05Allowed if exist separately
    0.05Not exceeding 8 places per filmNot exceeding 5 places per film
    Making marks Define an extanded 0.5 metar film per place Add one extra meter par place
    2Size
    2.1Thickness ( mm )0.38±0.020.76±0.02
    2.2UniformityHorizontal thickness warp should not exceed 15um at a distance of 25mm; horizontal Ehickness warp Should not exceed 20um at a distance of 50cm.
    2.3Length tolerance (m )0-50-2
    2.4Width tolerance ( mm )0-20
    3Moisture ( % )0.4-0.6
    4Extending intansion ( MPa )≥20.0
    5Ruplura extending rate (%)≥200
    6Fograge (%)<0.4
    7Shrinking rate (60/15min) ( % )≤12

    Quality Clear Construction Glass PVB Laminating Film Sound Insulation 0.38mm for sale
