Led Screen HD P3 Indoor Full Color Rental Led Display Die Casting
Cabinet
1. LED Chip: Supplied by Nichia of Japan & Cree of USA & Epistar of
Taiwan or other high strictly
selected LED chip, assure high definition show effect.
2. Wide viewing angle 120/160°, perfect and impressive viewing
effect.
3. High quality IC selection:
MBI5024/5035/5036/5039/5042/5124/5153, JXI5020, TLC59283 ,
ICN2053BP/2083S or other types you require.
4. Famous power supply selection: Meanwell, E-energy, Greatwall
etc., CE, UL certified.
5. Famous control system for optional: Synchronous: Nova, LINSN,
Mooncell etc.;
Aynchronous: Tianyi, Xixun or Betters etc.. They are stable, wide
application, easy to operate,
good refresh rate and grey scale, powerful functions to support
your need.
6. Skillful and strict assembly workmanship, can assure you high
quality guaranteed products.
7. All our products support 3 years warranty or more according to
your requirements.
8. Immediate, patient and considerated service is our principle.
9. All products are CE, RoHS, FCC, TUV certified.
| Unit Module Specifications |
| Item | P3 |
| Pixel Pitch | 3 mm |
| Pixel Configuration | 3in1 (1R1PG1B) |
| Module Size(MM) | 192*192 |
| Module Resolution(Dots) | 64*64 |
| Module Weight(Kg) | 0.3 |
| Package LED Mode | SMD2121 |
| Max Power(Watt) | 21 |
| Pixel Density(Dots/SQM) | 111'111 |
| Driving Method | Constant Current Driving |
| Scan Method(Scan) | 1/32 |
| Interface Way | HUB 75 |
| Brightness(CD/SQM) | ≥ 1500 |
| Safety Standard | CCC,FCC,ROHS,TUV,CE,ETL,UL,BIS..... |
| Unit Cabinet Specifications |
| Cabinet Size(MM) | 576*576 |
| Cabinet Composing(PCS) | 9 |
| Power Supply Mode(Per Cabinet) | 5V60A |
| Cabinet Resolution(Dots) | 192*192 |
| Optimal Viewing Distance(M) | 3-300 |
| Optimal Viewing Angle | Horizontal angle: 160 degree; Vertical angle: 140 degree |
| Environment Temperature | Storage: -40 degree ~ +85 degree; Work: -20 degree ~ +60 degree |
| Relative Humidity | 10% ~ 95% |
| Power Supply Specifications |
| Operating Voltage | AC:100V~120V AC:220~240V |
| Average Power(W/SQM) | 150-350 |
| Max Power Consumption(W/SQM) | ≤ 800 |
| Current | ≤ 20mA (single LED) |
| Control System Specifications |
| Computer | Pentium4 or above P4 or above |
| Operate System | Win7-11/2000/NT/XP |
| Control Mode | Synchronization with PC |
| Main Technical Parameter Specifications |
| Driving Device | Constant Current Driving |
| Refresh Rate | ≥ 1900-3840Hz |
| Gray/Color | RGB each 256 grade, can display 16.7color |
| Lifespan | ≥ 100000hours |
| Power Switch | RGX Automatic Switch |
| Display Mode | 2048*10241024*7681280*960mm |
| For more information please contact our sales. |
Die Casting Aluminum Cabinet Details, This Cabinet Is Light, Thin
And Is Easy To Intall For
Different Events.
Company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the
standard new factory, about 100 employees. We have outstanding
R&D department and after-sell service workers, and separately
design ability. Our product mainly included led indoor full color
display, led outdoor full color display,led indoor full color
display, led wireless car usd screen, poster screen,transparent
screen etc.It can be used on the shopping mall, bank, bus station,
train station, center of downtown, airport,school,factory,bus,taxi
and so on. We adapt many methods and very good after-sell service
to sell our product all over the world. Whenever and wherever we
are, we always take the principle that is: professional makes good
quality,good price product market to price product market to
provide perfect product and service for our customers.
Certificate
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
Our service
Warranty
1.We guaratee all our display, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the
operation and maintenance training of the LED screens in the
factory.
3.After warranty, we also can offer you the parts for replacement
at our bottom price.
4.After sales, if you have any problem about our product, you can
inform us by E-mail, we will reply you at once
when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you antil it recovers well by
remote control!
Installation
1.We can assist the training and technical support for the customer
in the factory, if the customer require so.
2.We could send our engineer to guide the installation to you. But
the relavant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the
LED Display rightly and fast, of course, if you need.
