    Compensation Free Trinocular Polarised Light Microscopy For Polarizing Observation

    XP-148PLT Compensation Free Trinocular Head polarizing microscope Stress-free Infinity Plan Objective


    Transmission polarizing microscope is a professional laboratory instrument which is the most commonly used in geology, minerals, metallurgy, material, etc, departments, and relative Universities and colleges. In recent years, with the advancing of optical technology, the polarizing microscope, as optical instrument, is to be used wider and wider, Transmission polarizing microscope is very suitable product which provides users to do single-polarized light observation, orthogonal polarizing observation, cone-ray observation and microscopic photography. It can also configure attachment like test piece of gypsum 1λ.mica1/4λ, quartz wedge and mechanical stage, It is a high quality novel instrument with more maturity functions.


    SpecificationModel
    148PLT
    Viewing HeadCompensation Free Trinocular Head Inclined at 30°(50mm75mm)
    EyepieceWF10×/20mm
    10×Gridding Eyepiece
    10×eyepiece with reticule
    NosepieceQuintuple Nosepiece with centering adjustable
    ObjectiveStress-free Infinity Plan Objective:4×,10×,25×,40×(s),63×(s)
    StageRotary Stage
    Stage Size:172mm
    Moving Range:360°
    CondenserSwing type N.A.1.25 Abbe condenser with iris diaphragm
    Testing PieceGypsum 1λ testing piece
    Mica 1/4λ
    Quartz wedge testing piece
    Focusing

    Coaxial coarse & fine focusing adjustmen. With rack and pinion

    mechanism. Fine focusing scale value 0.002mm

    IlluminatorHigh brightness fixed illumination
    Light SourceHalogen Bulb 6V/30W.AC85V230V
    Adjustable Brightness
    Checking Tool0.01mm Micrometer
    Optional Accessory

    Eyepiece: WF16×,WF20×,P16×

    1.3Mega,2.0Mega,3.0Mega,

    5.0Mega Pixels CMOS Digital camera eyepiece

    Stress-free objestive:100×(s)Oil

    Photography attachment and CCD Adapter0.5×,×0.57×,0.75×
