Warranty: | 5 years, More than 5 years |
After-sale Service: | Online technical support, Free spare parts, Other |
Project Solution Capability: | Others |
Application: | Office Building |
Design Style: | Industrial, glasswool |
Place of Origin: | Chongqing, China |
Brand Name: | HanJiang |
Model Number: | Rock wool |
Type: | Rock wool |
Shape: | Square |
Material: | Rock wool |
Core Material: | Rock wool |
Product Name: | Color steel rock wool sandwich board |
Width: | 930/1000/1120mm |
Certificate: | ISO |
Thickness: | 30/40/50/75/100/120/150/200/250mm |
Length: | Customized, less than 11.8m |
Function: | Thermal insulation |
Core density: | 40-48kg |
Products Description
Rock wool sandwich panel is a kind of sandwich panel made of rock
wool as raw material. The rock wool sandwich panel gives full play
to the unique properties of the rock wool core material, and has
remarkable effects in fire prevention, thermal insulation, sound
absorption and sound insulation, etc.
The disadvantage of rock wool sandwich panels is that they are not
strong enough, but they are suitable for steel structure workshops,
roofs, walls of simple mobile homes, ceilings and partitions of air
clean rooms, etc.
Products feature
1. Good rigidity: Since the rock wool core material and the two
layers of steel plates are bonded into a whole and work together,
and the upper surface of the roof panel is corrugated and pressed,
its overall rigidity is far better than that of the pressed plate
with rock wool (glass wool) cotton) on-site composite sheet. After
the sandwich panel is fixed with the purlin through the connector,
the overall rigidity of the roof is greatly improved, and the
overall working performance of the roof is enhanced. If rock wool
sandwich panels are selected, a larger purlin distance can be used,
so the amount of purlins can be saved by 1/3~2/3.
2. The buckle connection method is reasonable: the rock wool roof
panel adopts the buckle connection method, which avoids the hidden
danger of water leakage at the joint of the roof panel and saves
the amount of accessories.
3. The fixing method is firm and reasonable: the rock wool roof
panel is fixed with special M6 self-tapping screws and purlins,
which can effectively resist external forces such as typhoons.
Self-tapping screws are set at the crest position on the upper
surface of the roof panel, and a special waterproof structure is
adopted to avoid waterproof weak points.
4. Short installation period: rock wool sandwich panel, because
there is no need for secondary processing on site, not only can
keep the surrounding environment clean and tidy, without affecting
the normal progress of other processes, but also can greatly
shorten the installation period of the panel, and the rock wool
sandwich panel The average daily installation area is 600~800㎡.
5. Anti-scratch protection: During the production of rock wool
sandwich panels, a polyethylene self-adhesive protective film can
be pasted on the surface to avoid scratches or wear on the surface
coating of the steel plate during transportation and installation.
Application
Rock Wool Sandwich Panel is widely used in the roof, wall of steel
structure factory building, simple activity room, ceiling and
partition of air clean room. Rock wool sandwich panels can
generally be customized according to the requirements of customers.
Rock wool sandwich panels are the most superior in fire resistance
among the series of sandwich panels.
