    500Vac Microphone Splitter Transformer , AF Transformer Low Frequency

    Ask Lasest Price
    Brand Name : Shinhom
    Model Number : AT2510P
    Certification : ISO9001-2000, UL, ISO9001, CCC, CE
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 1000000/MONTH
    Delivery Time : 4~8 Weeks
    • Product Details
    • Company Profile

    500Vac Microphone Splitter Transformer , AF Transformer Low Frequency

    Microphone Split Transformer , AF Transformer


    Features:

    • Provides 2 additional, isolated balanced outputs as mic 'splitter'
    • Stops 'ground loop' problems when a mic feeds multiple preamps
    • High common-mode rejection: 130 dB at 60 Hz
    • Excellent frequency response and time domain performance
    • Low insertion loss: 1.2 dB


    Application:

    This transformer is designed for drive from a 150 Ω microphone source and for each secondary to be loaded by the 1 kΩ input impedance typical of microphone preamplifiers. A pair can be used to make a passive matrix when using the M-S stereo microphone technique. A 30 dB magnetic shield


    Electrical specification:

    • Inductance: 12-11: 3.0H±20%@1KHz,0.3V
    • 5-4: 3.0H±20%@1KHz,0.3V
    • 8-7: 3.0H±20%@1KHz,0.3V
    • DCR: 12-11: 50Ω±15%
    • 5-4: 51Ω±15%
    • 8-7: 58Ω±15%
    • Hi-Pot: 500Vac,5mA,1S Pri to Sec
