    Two Channel Polarizing Beam Splitter Cube 632.8nm AR Coating

    Two Channel Polarizing Beamsplitter Cube

    Overview:

    Standard polarizing beamsplitter cube does not have high advantate on the extinction ratio of reflected channel . This Two Channel Polarizing Beamsplitter Cube with our unique coating technique can achieve high performance not only at transmitted but also at reflected channels. It features greater than 97% transmission of p-polarized beam as well as high extinction ration of greater than 1000:1 at transmitted channel and 200:1 at reflected channel. It is widely used in interferometer applications.


    General Specification of Two Channel Polarizing Beamsplitter Cube:

    MaterialN-BK7
    Dimension Tolerance±0.2mm
    Surface Quality40/20 scratch and dig
    Clear Aperture>90%

    Transmitted Wavefront Distortion

    <λ/8@632.8nm per 10mm
    Reflected Wavefront Distortion<λ/8@632.8nm per 10mm
    Beam Deviation<3 arc minutes
    Extinction Ratio

    Tp/Ts>1000:1

    Rs/Rp>200:1

    Principal TransmittanceTp>97%
    Principal ReflectanceRs>99.9%
    CoatingPolarization beamsplitter coating on hypotenuse face
    AR coating on all input and output faces
    Damage Threshold>500mJ/cm2, 20ns, 20Hz, @1064nm


    Standard Products of Two Channel Polarizing Beamsplitter Cube:

    Part NumberMaterial

    Dimension

    (mm)

    Thickness

    (mm)

    Tp/TsRs/Rp

    Wavelength

    (nm)

    PBST1212-532N-BK712.7x12.712.7>1000:1>200:1532
    PBST2525-532N-BK725.4x25.425.4>1000:1>200:1532
    PBST1212-633N-BK712.7x12.712.7>1000:1>200:1633
    PBST2020-633N-BK725.4x25.425.4>1000:1>200:1633
    PBST1212-780N-BK712.7*12.712.7>1000:1>200:1780
    PBST2020-780N-BK725.4x25.425.4>1000:1>200:1780
    PBST1212-1064N-BK712.7*12.712.7>1000:1>200:11064
    PBST2020-1064N-BK725.4x25.425.4>1000:1>200:11064

    Coating Curves of Two Channel Polarizing Beamsplitter Cube:


    532nm Two-Channel High Performance

    Polarizing Beamsplitting Cube

    633nm Two-Channel High Performance

    Polarizing Beamsplitting Cube


    780nm Two-Channel High Performance

    Polarizing Beamsplitting Cube



    1064nm Two-Channel High Performance

    Polarizing Beamsplitting Cube


    Mount Options of High Power Polarization Cube Beamsplitter:

    Star Optic also offers a variety of mounting solutions for our Two Channel Polarizing Beamsplitter Cubes. Please refer to Optomechanical Mounts for information on mounting options and compatibility. If you are not sure which to select, please contact us, we will work with you to identify the best solution for your needs.
