    High Efficiency Air Cooled Screw Chiller 100HP with Double Compressors CE ISO9001

    Ask Lasest Price
    Brand Name : ANGES
    Model Number : 320HP
    Payment Terms : T/T
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    High Efficiency Air Cooled Screw Chiller 100HP with Double Compressors CE ISO9001

    Air Cooled Process Water Chiller Packaged Cooled Chiller System High Efficiency Chiller Plant Water Chiller


    Applications of chilled water system

    Chiller is a kind of cold water equipment that can provide cold water with constant temperature, flow rate and water pressure.

    Water chiller is widely used in plastic industry, it is a critical part for injection molding production process, to transfer heat away from the mold and maintain a stable cooling rate, ensuring the highest quality final products.


    Air-cooled screw chiller specification

    Model

    Parameter

    AGS-100ADH

    nominal cooling capacity

    kcal/h

    282080

    kw

    328

    input power

    kw

    93

    max running current

    A

    211.5

    power supply

    3PH/380V/50HZ

    refrigerant

    type

    R407C

    weight(kg)

    70

    refrigerating circuit

    1

    type of control

    thermostatic expansion valve

    compressor

    type

    semi-hermetic screw

    power(kw)

    37.4*2

    quantity

    2

    start-up mode

    Y-△

    capacity control

    0-33-66-100

    condenser

    type

    air cooled type finned copper tube

    cooling air flow (m3/h)

    105000

    power(kw)

    18

    evaporator

    type

    shell and tube

    quantity

    2

    chilled fluid flow (m3/h)

    56.4

    inlet and outlet pipe diameter (inch)

    4

    safety protection

    compressor over temperature protection,over load protection,high and low pressure protection,flow switch protection,reversed and lacking phase protection,anti-freezing protection.

    net weight

    kg

    3340

    running weight

    kg

    3540

    Dimension

    Mm

    4200x2200x2383


    Air-cooled screw chiller featurers

    1. Adopting high-efficiency and energy-saving compressors of world class grade brands, high-quality condensers and evaporators, high cooling efficiency, stable performance, low noise and long service life.

    2. The control system is adopting Siemens PLC controller and LCD touch screen , accurately controls the cooling capacity and cooling load of the unit in real time to achieve the best matching state, to ensure that the unit runs at the best efficiency and to reduce operating costs.

    3. Screw compressor chiller capacity control can adopt four-stage (100%-75%-50%-25%), three-stage (100%-66%-33%) or stepless control system.

    4. High-efficiency internally threaded copper pipes enhance the heat transfer effect are more energy efficient.

    5. The machine is all made of oshell and tube evaporator and condenser, the welded structure is simple, sturdy structure, high quality, compact structure, long life and so on.

    Advantages of Air-Cooled Chillers

    • Easy Installation – Air-cooled chillers do not require a cooling tower or additional water piping, making them easier and more cost-effective to install.

    • Lower Maintenance – Since there is no need for a cooling tower, air-cooled chillers eliminate issues like water treatment, scaling, and algae growth, reducing maintenance costs.

    • Flexible Placement – Air-cooled chillers can be installed outdoors without the need for a dedicated mechanical room, making them ideal for locations with limited indoor space.

    • Water Conservation – Unlike water-cooled systems, air-cooled chillers do not require continuous water supply, helping to conserve water resources and lower utility costs.

    • Reliable Performance – With fewer components like cooling towers and water pumps, air-cooled chillers have a simpler system structure, reducing the risk of failures and ensuring stable operation.

    Benefit of process chiller

    • The ability to maintain constant and precise control of the process temperature.
    • The cooling fluid can be delivered directly to the application heat source to increased production speed and ensure efficiency production
    • Accurate temperature control capability, to ensure the highest quality final products.
    • Water chiller systems prevent damage to heat-sensitive industrial components preventing undesirable repair downtime that might slow or even halt production altogether.

    Chiller service

    1. All the chillers are provided with 12 months free maintenance service.
    2. Provide technical explanation, chiller debugging support, technical training and chiller maintenance guidance.
    3. If necessary, after-sales engineers can be on-site service confirmed by both parties through communication .In some areas, local dealers can provide fast and convenient service.
    4. Provide the air chiller and water chiller required parts quickly to ensure the normal use of customers.If necessary, part of the wearing parts can be provided for backup after confirmation by both parties.
    5. Chiller maintenance service outside the warranty period, life-long tracking maintenance, cost price to provide equipment parts.
