CBB20 15uF 700VDC Polypropylene Audio Film Capacitors Frequency Modulation

    Buy cheap CBB20 15uF 700VDC Polypropylene Audio Film Capacitors Frequency Modulation from wholesalers

    Buy cheap CBB20 15uF 700VDC Polypropylene Audio Film Capacitors Frequency Modulation from wholesalers
    • Buy cheap CBB20 15uF 700VDC Polypropylene Audio Film Capacitors Frequency Modulation from wholesalers

    CBB20 15uF 700VDC Polypropylene Audio Film Capacitors Frequency Modulation

    Ask Lasest Price
    Brand Name : ETOPMAY
    Model Number : TMCF20
    Certification : SGS( RoHS)
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 100000pcs per month
    Delivery Time : 25~35 working days after payment
    • Product Details
    • Company Profile

    CBB20 15uF 700VDC Polypropylene Audio Film Capacitors Frequency Modulation

    CBB20 15uF 700VDC Polypropylene Audio Film Capacitors Frequency Modulation


    Feature:

    • Down-leads axially and horizontally.
    • Very low loss at high frequency, suitable for high current.
    • High Insulation resistance, long life due to self-healing effect.
    • Widely used in high frequency, DC, AC and pulse circuits.

    Specifications


    Referance StandardGB 10190-88(IEC 60384-16)
    CBB20 250V Axial Metalized Polypropylene Film Capacitor for Audio
    Climatic Category40/85/21
    Rated Voltage700VDC
    Capacitance15μF
    Capacitance Tolerance±10%(K)
    Voltage proof1.6UR(5s)
    Dissipation Factor≤0.1%(20℃, 1KHz)
    Insulation Resistance≥25000MΩ (CR≤ 0.33 uF) ≥7500S (CR≥0.33 uF) (20℃,1min)

    Dimension


    ItemDiameter(mm)Length(mm)Lead Diameter(mm)
    TMCF20-156K700VB34501.2

    FAQ Of Topmay Capacitor


    1) Can I have a free sample to test ?
    Yes, we could provide free samples to test and check quality. Freight cost is collected.

    2) What is the lead time?
    Sample needs about 7~10 working days prepared; mass production average time takes 15-20 working days

    3) Do you have any MOQ limit?
    Yes. But it depends on product. Normally MOQ is 2K~10Kpcs

    4) How about price terms?

    We do FOBSHENZHEN if order amount is more than 5000USD. Less than that, it is EXWSHENZHEN and we do not undertake local charge.

    5) What information should I let you know if I want to get a quotation?

    Basically for capacitor, it requires to know detailed capacitance and voltage. If you have more information, such as type, product photo for reference, you could kindly provide too.
