Overview:
The Piggable 5D Elbows are specially manufactured to provide a
smooth pig passage and minimize the increase in pressure
requirements. Pigging elbows are available for any pipe size, plan
and material configuration. The centerline bend radius of piggable
elbows is usually 3 or 5 times the nominal pipe diameter. Elbows
are specially manufactured to meet tight ovality tolerances. They
have welded tangents on both ends to prevent the pig from hanging
up and to ensure the pig runs smoothly through the elbow.
Characteristics:
The following functions can be realized through Pigging
- Optimal use of resources
- Increase yields
- High-accuracy pipe Pigging System
- Reduce flush waste
- Save time and money
- Reduce contamination risks, free of residual
- Changeable lips of pig can minimize the cost of consumer.
- Increased economic efficiency in production
Parameters:
Port Type | ASME B16.5 RF |
| Pipe Size | 1.5”~8” |
| Pressure Standard | ANSI 150# |
| Material | WCB,CF8,CF8M,Alloy |
| Liquid Viscosity | 0.1～440,000 cst |
| Liquid Temperature | -52～380℃ |
| Product Category | ASME B16.5 RF Launcher Receiver Pig Stop T-way valve Three-way distribution valve 5D elbows Pig Pigging line Electric cabinet Control System |
Pictures:
Applications:
- Chemical product
- Pier location product
- Manual & automatic control
- Pigging relevant accessories.
F&Q:
Q1: What can pigging system do in pipeline?
A: BJVP Pigging System can use the pig to clean the pipe line.
There is no redidue and contamination between the different kind of
liquid sharing the same pipe.
Q2: What is pigging equipment?
A: BJVP pigging equipment includes items such as high finishing
pipe Pigging System, pig launcher/ receiver, middle station, pig
detectors, pig, etc.
Q3: Where can this pigging system be used?
A: BJVP pigging equipment can be widely used in Lubricants and
greases, paints and varnishes, special chemicals, perfumes and
other industry applications.
Q4: How do pigs clean the pipelines?
A: Pig is pushed by forced air from the launcher to receiver, so
the product and any residues in pipeline will be pushed out of the
pipeline by pig.
