    Tincture Perfume Glass Bottle Vial Filling Capping Machine 316SS

    Ask Lasest Price
    Brand Name : YIMU
    Model Number : YMF4C1
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 30 sets per month
    Delivery Time : 30-35 days
    • Product Details
    • Company Profile

    Tincture Perfume Glass Bottle Vial Filling Capping Machine 316SS

    Automatic Tincture Perfume Essential Oil Liquid Reagent Dropping Glass Bottle Filling Capping Machine

    Automatic Dropping Bottle Filling & Capping Machine is adopts disc positioning filling and single head for capping, which is suitable for both materials and dropping bottles of different specifications. The structure of the machine is compact and reasonable, and it is convenient for it to form a working line together with other equipment. There is a O-type sealing ring on the top of the piston in the pump. The parts on the working table of the machine frame are made of 304 and 316 stainless steel. The running parts are made of high-quality steeland the surface is specially treated. The whole machine is reasonable in structure, stable in operation and convenient in maintenance.
    Main Application:Applied to liquid filling in pharmaceutical, food, chemical and other industries.

    Functions:

    1.Adopt peristaltic pump in common use in special use to fill high precision, large range of adjusting dosage.

    2.Low level liquid receiver, be convenient to clean.

    3. Stronger PLC software support, may realize the ideal filling operation.

    4. The touching operation color screen, can display the production state, operation procedures and filling ways, tableau objective, operation simple and maintenance convenient

    5. Filling nozzles is specific for small bottle mouth, no leak.

    6. Machine can arrange and feeding drop cap and screw it on bottle mouth tighten.

    7.Filling and capping are in one body of bottle to the machine, economical and low space possessing.

    8.The whole machine is designed according to requirements of GMP.


    Technical parameter:


    Filling volume5-100ml
    Tolerance of filling quantity

    ≤±1% standard filled quantity

    Yield of cap-rotating

    ≥99.8%
    Power supply220V 50Hz,1phase
    Power2KW

    Air supply

    0.3-0.8MPa
    Air consumption18~20 m³/h
    Weight

    approx.600kg

    Overall dimension(L*W*H)2500*1000*2000mm
    Production capacity(30ml)1200-2400bottles/hour
