    Galvanized Steel ERW Pipe Mill for Square Tube 100x100-200x200mm

    Ask Lasest Price
    Brand Name : Tengtian
    Model Number : 200x200
    Certification : CE,ISO9001,BV
    Price : $100000 to $1 million
    Payment Terms : L/C,T/T,Western Union
    Supply Ability : 30 Sets
    Delivery Time : 150 work days
    • Product Details
    • Company Profile

    Galvanized Steel ERW Pipe Mill for Square Tube 100x100-200x200mm

    Galvanized Steel High Frequency Square Pipe Erw Pipe Mill

    Product Description:

    Galvanized Steel High Frequency Square Pipe Erw Pipe Mill is used to manufacture welded steel pipe.After we absorbed advanced pipe making technology from both abroad and domestic, can product different size,shape tube and ensure the tube precision.the square tube size:100x100-200x200mm, tube thickness: 5.0-10.0mm,also can product LTZ special shape tubes.

    Main Parameters and Specifications:

    Material Specifications

    • Conforming to the YB189-64 standard
    • steel material: Q235/Q345
    • Mechanical properties:σb≤380Mpa,σs≤275MPa
    • strip width:400-800MM
    • strip thickness:5.0-10.0MM
    • I.D of Coils:Φ508mm
    • O.D of Coils:φ2000mm
    • Coil Weight:10TON

    Quality and Service Warranty

    After the machine arrives at the buyer,technical service person will go to buyer factory provide guidance on operation,debugging and maintenance the machine,responsible for technical training for equipment operation and maintenance personnel of the buyer.

    whole line warranty one year


    Working Process:

    strip steel to coil→uncoiler →shear welder→storage material unit →formed,welding,cooling,accurate pipe Dia. size →accurate pipe length size,cutting→inspection →package
    Tube Mill Other Model

    ModelDiameter RangePipe ThicknessLine Speed(m/min)
    HG208-25.4MM0.3-1.2MM120
    HG3210-32MM1.4-1.5MM120
    HG5016-76MM0.7-2.5MM30-120
    HG7625-76MM1-4MM30-100
    HG8932-89MM1-4.5MM30-80
    HG11445-114MM1.5-5.0MM30-60
    HG16560-165MM3-7MM30-50
    HG219114-219MM4-8MM20-40
    HG273114-273MM4-10MM15-30
    HG325165-325MM4-10MM10-30
    HG426165-426MM4-12.7MM8-25
    HG508219-508MM4-16MM8-20
