    15.0 Inch Industrial LCD Panel RGB 1024X768 LVDS 20 Pins HM150X01-102

    Ask Lasest Price
    Brand Name : BOE
    Model Number : HM150X01-102
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100000 Unit/Units per Month
    Delivery Time : 7 Days
    • Product Details
    • Company Profile

    15.0 Inch Industrial LCD Panel RGB 1024X768 LVDS 20 Pins HM150X01-102

    New Original 15.0 inch 1024(RGB)×768 Lvds 20 Pins Industrial LCD Panel HM150X01-102


    HM150X01-102 Product details :


    BOE LCD SCREEN HM150X01-102
    ManufacturerBOE
    Model NameHM150X01-102
    Screen Size15.0 inch
    Screen TypeLCM , a-Si TFT-LCD
    Pixel Number1024(RGB)×768 (XGA) 85PPI
    ArrangementRGB Vertical Stripe
    Active Area(mm)304.128 × 228.096 (H×V)
    Outline(mm)326.5 × 253.5 × 11.9 (H×V×D)
    Bezel Area(mm)307.4 × 231.3 (H×V)
    TreatmentAntiglare (Haze 25%), Hard coating (3H)
    Luminance350 cd/m² (Typ.)
    Contrast Ratio700 : 1 (Typ.) (TM)
    Viewing Angle80/80/80/80(Typ.)(CR≥10)
    Response8(Typ.)(Tr+Td) ms
    Work ModeTN, Normally White, Transmissive
    Color Depth262K/16.2M 60% NTSC
    Backlight9S3P WLED , 50K hours , With LED Driver
    Mass1.04Kgs (Typ.)
    Used forIndustrial Medical Imaging
    Refresh Rate60Hz
    TouchscreenWithout
    Signal TypeLVDS (1 ch, 6/8-bit) , 20 pins Connector
    Voltage Supply3.3V (Typ.)
    Max. RatingsStorage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
    New Original 15.0 inch 1024(RGB)×768 Lvds 20 Pins Industrial LCD Panel HM150X01-102
