Stainless Steel Automatic Mushroom Vertical High Pressure Autoclave
Steam Sterilizer
• Full SUS 304 stainless steel structure
• Accurate dual scale indicates pressure gauge
• Silicone seal ensuring no steam leakage
• Spin buttons to set sterilization temperature and time
• Blue, orange, and red light showing work status
• Automatic release when overpressure
• Water shortage and over heating protection
• Drying action can be added (Best large than 75L volume)
Specifications
Model | Chamber Size | Overall Size | Net Weight | Steam | Water | Power |
W*H*D mm | W*H*D mm | Kg | Kg/cycle | Kg/cycle | KVA |
MD-0.8Y | 680*1180*1000 | 2200*2000*1410 | 1480 | 35 | 280 | 3 |
MD-1.0Y | 680*1180*1250 | 2200*2000*1660 | 1630 | 40 | 300 | 4 |
MD-1.2Y | 680*1180*1500 | 2200*2000*1910 | 2030 | 45 | 320 | 4 |
MD-1.5Y | 680*1180*1870 | 2200*2000*2280 | 2230 | 50 | 350 | 4.5 |
MD-2.0Y | 1000*1200*1700 | 2800*2000*2110 | 2490 | 60 | 400 | 4.5 |
MD-3.0Y | 1000*1500*2000 | 2800*2200*2410 | 3050 | 90 | 500 | 5 |
MD-4.0Y | 1000*1500*2670 | 2800*2200*3080 | 3700 | 120 | 600 | 6 |
MD-5.0Y | 1000*1500*3340 | 2800*2200*3750 | 4600 | 150 | 700 | 8 |
MD-6.0Y | 1000*1500*4000 | 2800*2200*4410 | 5400 | 180 | 800 | 8 |
MD-8.0Y | 1000*1500*5340 | 2800*2200*5750 | 7000 | 240 | 1000 | 12 |
Product Features
1. Bolt structure
2. High quality stainless steel material
3. Microcomputer automatic control, arbitrary set of sterilization
parameters
4. Safety interlocking device
5. Digital display and touch buttons
6. Standard test interface
7. Self-expanding seal
8. The container with automatic protection function:
overtemperature protection; overpressure protection self-discharge;
low water level protection, anti dry burning with stainless steel
bucket or basket
9. Buzzer reminder after sterilization, automatic stop.
10. Automatic cooling air, sterilization end automatic exhaust
steam
Description:
Backed by rich experience, we have emerged as one of the leading
manufacturers, exporter, distributor, wholesaler and suppliers of
automatic Autoclave Steam Sterilizer. The offered Autoclave Steam
Sterilizer are provided in diverse dimensions and specifications
as per customer’s demand.These steam sterilizers are manufactured
after taking all the requirements of customers by using high
quality of material & technology.
Ø Chamber Stainless Steel quality 304
Ø All outer body parts are stainless steel
Ø Fully automatic PLC control panel with online printer
Ø Short start up time
Ø Option to operate on 105℃ to 134℃
Ø Fitted with heavy duty vacuum pump
Ø Over 99.9% of air expulsion through purging
Ø 6 programmable cycles option for varying load i.e.
· Pre Start cycle
· Leakage Test
· 2-3 cycles for different loads @ 121℃
· 2-3 cycles for different loads @ 134℃
Ø Sliding Door Mechanism Double motorized
Ø High quality Silicone Gasket
Ø Pneumatic Door sealing system
Ø Stainless Steel Trolley systems
Applications:
Cloth, rubber stoppers, instruments, unsealed containers, media,
animal cages, mushrooms soil and seasonings.
Competitive Advantage:
Easy to use – one touch operation.
Large capacity – From 800 to 8000 liters
Highly customizable – with a wide range of accessories and options.
Fast and economical – sterilization cycles from 21 minutes with
advanced water and
energy saving systems.
Best solution – for pharmaceutical and biotechnological
applications.
Brochure load down from here
Medpharm medical large steam autoclave brochure.pdf
