High Quality Powder Coat Curing Tunnel Oven
| Powder coating oven |
| Outside Size | 3500 x 2700 x 3000mm(LXWXH) |
| Inside Size | 3200x 2400 x 2700mm(LXWXH); |
| Wall panel | Rock wool steel board,150 mm thick,anti-flame and heat-insulation |
| Heating system OPTION 1 | 1set of Riello FS20 natural gas burner,200000Kcal/h |
| stainless steel heat exchanger,max temp:220 ℃, heating time: 20-25
min (180-220℃). |
| Circulation fans:1 set 3.0kw high-temperatute resisting fan,air
flow capacity:3000m3/h.Fan and burner box inner is 2 mm thick galvanized
steel,interlayer 150mm thick rock wool,out is 1.2mm thick
galvanized steel to keep heat |
| Control system | Temperature alarm(With inductor in the oven) ,stop button,process
setting system:could set baking time and temperature,when baking
time arrive,stop automaticly |
| Total power | 3kw |
Powder coating oven with track rail:
Powder coating oven components:
Customization of powder coating line
Before customized design for your painting line, there are some
points needing your confirmation:
1). What's the size (L*W*H) of your workshop for this painting
line?
2). What's the shape, size(L*W*H), weight of parts to be painted?
Could you please send
me some pictures of the parts?
3). How many parts to be painted in a working day (8hours)?
4). Is there any oil or rust on the surface of the parts? If yes,
how about the amount?
5). How many times do you want to paint such parts?
6). What's your desired heating source for baking the paint,
diesel, natural gas or electric?
7). How about the electric voltage and frequency in your palce?
Why Choose Colin
1. Provide professional person to communicate with you before the
order.
2. Provide powder coating line with advanced technology, exquisite
workmanship,
top design.
3. Provide strict quality check for each part, each process before
export.
4. Provide optimum system solution based on each client’s specific
requirement and
local location’s weather condition.
5. Provide complete post-sale service, including installation,
technical guide and training.
1.What payment do you accept?
Irrevocable L/C at sight and T/T.
2.What is your payment terms?
30% T/T deposit, 70% T/T or irrevocable L/C at sight before
shipping.
3.How long will you need for producing the products?
Usually we will start purchase raw materials after receiving the
deposit and start producing, normally will need 30-35 working days.
4.What is your main products?
Our main products are powder coating line, powder coating
booth(manual type and automatic type), powder coating oven,
pretreatment system, water curtain booth etc.
5.Can you install for us?
Sure, we have a experienced and professional overseas installation
engineer team at your service.
