Absolute Parallel Micro Single Turn RS485 SSI BISS Multi Turn 23 Bits Encoder

Absolute patallel micro single-turn RS-485 SSI BISS multi-turn 23 Bits encoder

1. Feature: single-turn multi-turn, flange encoder, SSI BiSS, RS-485 interface, 14-24mm hollow shaft

2. Application: Servo Motor, robot and other industrial automation field.

3. Important parameter: Resolution up to 24 bit, protection grade IP50.

Basic Paramenters

Items	Basic parameters
Brand	Hengxiang
Encoder type	Absolute encoder
External diameter	55mm(Mounting flange 65mm)
Thickness	15mm
Hollow shaft type	Through hole
Hollow shaft diameter	14mm; 15mm; 19mm; 20mm; 24mm
Resolution	single-turn:17Bit, 19Bit,20Bit, 22Bit, 24Bit
	multi-turn: 1716=17+16Bit, 1916=19+16Bit,
	2016=20+16Bit, 2216=22+16Bit,2416=24+16Bit
Interface	E=SM08B-GHS-TB ；J=radial cable
Communication	B=BISS-C; S=SSI
Electrical connection	R=RS-485
Output mode	M=multi-turn
Output mode	S=single-turn
Scanning principle	Reflective grating code
Accuracy	±80"
Response speed	Normal action: 6000min-1
RMS position signal noise	±2@18 bits/r
Communication clock frequency	≤10MHz(BISS) or ≤ 5MHz(SSI)
Starting time	typical value: 13ms
Absolute position sampling period	≤75 ns
Allowable speed	≤32200 r/min (restricted by mechanical speed limit)
Cable	Differential twisted-paired cable
Cable length	200mm-10000mm
Mechanical Connection	With bearing& encircled locking shaft
Starting Torque	less than 9.8×10-3 N.m
Inertial moment	less than 6.5×10-6 kg.m2
Shaft load	Radial 30N; Axial 20N
Slew speed	≤6000rpm
Shell Material	Aluminum
Environmental temperature	Operating: -20~+95℃; Storage: -25~+100℃
Environmental humidity	Operating and storage: 35~85%RH(Noncondensing)
Vibration	Amplitude 1.52mm, 5~55HZ,2h for X,Y,Z direction individually
Shock	980m/s2 11ms, three times for X,Y,Z direction individually
Protection	IP50
Net weight	About 150g
