| 1.General Characteristics | | | Application: | this specificaiton is applied to rotary encoder used for general. | | Operating Temerature Range | 140℃ to +85℃ | | Operating Relative Humidity | ≤85%RH | | Test Conditions: | Unless otherwise specified.the atmospheric conditions for making
measurements and tests are as follows. | | Environment Temperature:5-35℃ | | Relative Humidiey:45-85% | | Atmospheric Pressure:86-106Kpa(860-1060mbar) | | Merchanical Life | 30000 cycles | | Electronics Life | 30000 cycles | | | | 2.Appearnace | | | Appearance | The encoder shall have good finishing ,and no rust,crack or plating
defects. | | Ratings | 5VDC 0.5mA | | | | 3.Electrical Characteristics | | | Contact Resistance | 200mΩ | | Insulation | 50mΩ Min. | | Dielectric Voltage | AC50V test 60s,Nodielectric breakdown shall occur | | Switching Characterist | Chattering Fig.2 t1,t3<3ms | | | | 4.Mechanical Characteristics | | | Detent Points | 12 detent points each detent angle:30 | | Output Waves | 12pulse/360° | | Rotational Force | 10±5gf.cm | | Terminal | Shall be free from terminal looseness,damage and insulator
breakage. |
| |
Company Introduction
Dongguan TianQian Electronics Co., Ltd.established in 2013,it is
specialized in design, development and production of high precision
components such as Rotary Potentiometer, Sliding Potentiometer,
Foot Switch, Band Switch, AC Switch, Sensor, Encoder, Tact Switch
and Connectors. The products are widely used in Dimmable Lighting,
Audio Mixer, Home Appliances, Automobile, Multimedia, Audio
Equipments, Instrument, Toys, Aviation Model and Communication
Equipments. We have an area of 3,000 square meters of factory
building. Our R&D team members have more than 20 years
experience in the component industry. In order to meet the high
quality demand from worldwide customers, we widely use automated
production lines which can output more than 80% of annual
production capacity. It takes pride in the achievement that we have
been the key supplier of JVC, Brother, IKEA, Midea, Microsoft,
Honeywell, Sennheiser, Primax and GGEC...etc. With the consistent
enterprise principles "Striving Excellence" & "Quality Assurance",
we hope both parties can establish a mutual benefit relationship
and create a win-win situation.
Applicaiton
We have a full range of special potentiometers, encoders and
switches ,which are widely used for mixers,instruments, effects,
car audio,air condition, lithgting control and household appliances
contral panels ,all products are welcome customized.
FAQ
Q1--What is your MOQ?
In general ,our MOQ is 500 pcs, it will be more convenient and
safety on packaging. Of course, it can be negotiable according to
your situation.
Q2--What is the delivery time ?
3-7 days for samples; 10-30 days for batch goods.
Q3--Can you give me samples to test and how many samples?
Yes, we provide free samples, with shipping and taxes paid by the
buyer. Usually, free samples are 1~10 pieces.
Q4--Does your products through UL, ROHS certification and so on?
Yes, our switches are with UL, CUL, VDE, TUV, ENEC, CE, CQC, Nemko,
CB approved, meet EU, RoHS standard.
Q5--Can you accept OEM?
Yes, we can accept OEM and ODM, they are welcome by us. But please
offer us your authorization certification.
Q6--Is there cheap shipping cost to our country?
For small order, express will be best. And for bulk order, shipping
by sea is better, but it takes much time.
Our advantage
Above 20 years specializing in manufacturing potentiometer, rotary
switch .encoder and etc.
Certificate: ISO 9001: 2008, RoHS, UL. etc.
According to your requirement to customize.
