50KW 76KWH battery energy storage system for solar hybrid system solution

Product name: 50KW 76KWH battery energy storage system for solar hybrid system solution

General

Capacity: 100KW/215KWh；

BESS uses customized outdoor cabinet; The container has battery compartment (battery cluster, BMS, illuminating system, air conditioner system, fire safety system and surge protection devices etc...); AC compartment (PCS, EMS, Transformer, Switches, Busbar, Cables etc...).

BESS can be using for peak shaving, energy back up, virtual capacity increase...

PCS Capacity

Total PCS capacity is 100KW; which contains 1*100KW PCS. Every single PCS connects to 1 battery cluster.

Battery cluster

280AH cell;

Battery Pack:1P16S,280AH×3.2V×16=14.3KWH; 3.2*16=51.2V

Battery cluster:1P15S,15×14.3=214.5KWh; 51.2*15=768V

1 battery cluster is 214.5KWH, total system is 214.5KWh, contains 1 battery clusters.

FAQ:

1. Are you factory or only company?

Shenzhen New Hong Energy Co.,Ltd, founded in 2021, the subsidiary of Haisic as overseas sales team.

Shenzhen Haisic Technology Co., Ltd, Founded in 2011, is a national high-tech enterprise dedicated to the research, development, and production of lithium batteries such as LifePO4 battery packs, solar energy storage batteries and systems, solar portable power stations/generators and solar powerwalls. Deeply engaged in this field for more than 11 years, Haisic Technology has accumulated profound experience in R&D, innovation, quality control and management. Our products are used in home energy storage, industrial energy storage, commercial energy storage, power communication, medical electronics, security communications, transportation and logistics, new energy power, smart home and other related fields.

We have owned our own production base covering more than 16000 ㎡ located in Dapeng district of Shenzhen with ISO9001, ISO14001, ISO45001 and Amfori BSCI, and our products are with CE, FCC, TUV-UL2054, CQC, RoHs, PSE, MSDS, UN38.3 certificates.We've already provided safe, stable, environmentally friendly, high-quality products and professional OEM/ODM services to customers in more than 60 countries and regions.
