4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting

    Buy cheap 4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting from wholesalers

    Buy cheap 4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting from wholesalers
    • Buy cheap 4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting from wholesalers
    • Buy cheap 4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting from wholesalers
    • Buy cheap 4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting from wholesalers
    • Buy cheap 4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting from wholesalers

    4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting

    Ask Lasest Price
    Brand Name : ManaNova
    Model Number : CNGA120408
    Certification : ISO9001,14001.18001, RoHS
    Price : $20-40/ Piece
    Payment Terms : L/C, T/T, D/A, D/P
    Supply Ability : In stock
    Delivery Time : 3-4days
    • Product Details
    • Company Profile

    4N Tips CNGA120408 PCBN Cutting Tools Carbide Inserts For Metal Cutting

    CNGA 120408 Standard PCBN Carbide Turning Insert PCBN Cutting Insert for cast iron


    Application:

    MHN10CApplied to the continuous cutting of hardened steel
    MHN20CApplied to medium interrupted cutting of hardened steel
    MHN30CApplied to the heavy interrupted cutting of hardened steel
    MKN10Applied to the cutting of gray cast iron
    MKN20Applied to the cutting of ductile iron
    MSN10Applied to the cutting of powder metallurgy
    MSN20Applied to the cutting of powder metallurgy

    Description:

    As a high-end standard cutting tool series, MANANOVA carries out the whole process of quality

    management from raw materials, with sophisticated production testing equipment, professional and

    experienced R&D and production team, and professional technical services, so that every user can

    continue to experience Worldia cutting tools advantages.


    Main products:
    “Seven material/ one type” namely each specification corresponding to seven materials

    (MHN10C ,MHN20C ,MHN30C, MKN10,MKN20,MSN 10)is the feature of the PCBN insert.


    PCBN insert is suitable for machining hardened steel, gray cast iron, ductile iron, and powder metallurgy.


    The four edge types of PCD insert are standard, chip breaker, full length, and full face.
    PCD insert (MND10 material ) is suitable for rough and finish machining of aluminum alloy and other non-metal materials.


    Service:
    · Online store service
    · Local distributor support
    · Technical support


    Specification:

    Material Introduction - Easy choice for CBN Grade

    ISO H: Hardened Steel Continuous cutting

    ISO K: Cast Iron Light interrupted cutting

    ISO S: Powder Metallurgy Heavy interrupted cutting

    MaterialISO HISO KISO S
    PCBN GradeMHN10CMHN20CMNH30CMKN10MKN20MSN10MSN20
    SmoothModerateToughnessCast IronDuctile IronPowder MetallurgyPowder Metallurgy
    Vc180(150~250)
    m/min
    100(50~150)
    m/min
    80(30~120)
    m/min
    600(300~800)
    m/min
    300(150~450)
    m/min
    300(200~500)
    m/min
    500(300~800)
    m/min
    fn0.1(0.03~0.2)
    mm/r
    0.1(0.03~0.2)
    mm/r
    0.1(0.03~0.2)
    mm/r
    0.1(0.03~0.3)
    mm/r
    0.1(0.03~0.3)
    mm/r
    0.1(0.03~0.3)
    mm/r
    0.1(0.03~0.3)
    mm/r
    %45~5560~7085~9585~9560~7060~7085~95
    Grain size1~2 um1~2 um2~3um2~3 um1~2 um1~2 um2~3 um
    BondTiCTiNCo/WCo/WTiCNTiCNCo/W

    CNGAShapeDimensions
    ANSI CodeISO CodeTipsIC
    mm
    S
    mm
    R
    mm
    Φd
    mm
    LE
    mm
    All
    Stocked
    CNGA 431CNGA 1204042N12.74.760.45.162.2
    CNGA 432CNGA 1204082N12.74.760.85.162.2
    CNGA 432CNGA 1204084N12.74.760.85.162.2
