K3V63 Hydraulic Pump Spare Parts
We Provide Hydraulic Pump Spare Parts. Spare parts include: Rotary
Group, Drive Shaft, Support, Swash Plate, Thrust Plate, Retainer
Plate, Set Plate, Ball Guide, Piston Shoe, Cylinder Block, Valve
Plate and other parts. 100% Compatible With Original Kawasaki, Good
Quality Piston Pump Parts And More Cost Effective Price.
| Item No. | Name & Description | QTY (pcs) | Remark |
| 1 | K3V63 DRIVE SHAFT | 1 | SHAFT |
| 2 | K3V63 SUPPORT | 1 | |
| 3 | K3V63 SWASH PLATE | 1 | YOKE |
| 4 | K3V63 THRUST PLATE | 1 | SHOE PLATE |
| 5 | K3V63 RETAINER PLATE | 1 | SET PLATE |
| 6 | K3V63 BALL GUIDE | 1 | |
| 7 | K3V63 COIL SPRING | 9 | |
| 8 | K3V63 PISTON SHOE | 9 | PISTONS |
| 9 | K3V63 WASHER | 1 | |
| 10 | K3V63 CYLINDER BLOCK | 1 | BARREL |
| 11 | K3V63 VALVE PLATE | 1 | PORT PLATE |
Features
K3V series: K3V63, K3V112, K3V140, K3V180, K3V280
1. With new technology the K3V series has realized higher power
density.
2. K3V series can cope with enlargement of displacement despite the
same installation dimensions and regulator variations as K3V’s.
3. K3V series pumps have realized higher reliability and long life
so as to meet requirement of larger torque.
| Model | K3V63 | K3V112 | K3V140 | K3V180 | K3V280 |
| Displacement /cm3 | 63 | 112 | 140 | 180 | 280 |
| Pressure MPa (kgf/cm2) | Rated | 34.3 (350) |
| Peak | 39.2 (400) |
| Speed /min-1 | Max.for self priming | 2,650 | 2,360 | 2,150 | 1,950 | 1,600 |
| Max | 3,250 | 2,700 | 2,500 | 2,300 | 2,300 |
Advantages
1.Strong part number database.
If you can provide the right model and part number, we can supply
the right product.
2.Professional and experienced salesperson.
Our founder has been into this field for more than 10 years, with
rich experiences.
3.Strict and complete company rules.
We will try our best to meet customer’s delivery time. Before
delivery, we must verify the part number or pictures of products
one by one, to make sure that customers can receive high-quality
and right-quantity goods.
4.Good management system.
No matter how big or small order, as long as customers place the
order, we will provide exporting service free for charge.
5.Good service attitude.
If the customer has any questions about the product, In our
receiving and knowing the situation, we will help the customer to
solve the problem in the first place.As long as customers’
requirements are reasonable, we will endeavour to make them
satisfied.
We offer wide range of hydraulic pumps that can suit to excavator
such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi,
Hyundai, Volvo.
All of our Hydraulic Pumps are packed well in wooden case.
