UNS N08825 Incoloy Hastelloy Plate 825 Sheets Thickness 0.9 Mm Laser Cutting

Ask Lasest Price
Brand Name :	BAOSTEEL
Model Number :	Incoloy 825
Certification :	CE, ISO, BV, SGS
Price :	15 - 30 USD/Kg
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	5000 tons per ton
Delivery Time :	7-12 days

Add to Cart

Product Details
Company Profile

UNS N08825 Incoloy Hastelloy Plate 825 Sheets Thickness 0.9 Mm Laser Cutting

UNS N08825 Incoloy 825 Sheets and Plates Thickness 0.9 - 40.0mm Laser Cutting as Request

Products Specification

Products Name	Incoloy 825 sheet and plate
Thickness	0.8 - 40.0mm
Width	1000mm 1219mm 1500mm or customs as request
Length	2000mm 2438mm 6000mm or customs as request
Surface	2B NO.1
Brand	BAOSTEEL
Service	Cutting Bending
Other Grade	Monel 400 500 Hastelloy C276 C4 inconel 625 600 .etc
MOQ	200 Kgs
Deliver time	within 12 days
Packing	waterproof paper and wooden pallets
Loading Port	Shanghai

UNS N08825 Incoloy 825 is a nickel-iron-chromium alloy that contains small amounts of titanium, copper, and molybdenum. Incoloy® 825’s chemical composition provides great resistance to many corrosive environments, such as pitting, crevice corrosion, intergranular corrosion, and stress- corrosion cracking. Incoloy 825 nickel alloy has good mechanical properties from moderate to high temperatures, with a hot- working range of 1600 to 2150º F. Alloy 825 also maintains good weldability for all conventional processes.
At Magellan Metals, we are an industry-leading provider of exceptional quality Incoloy 825 products including Incoloy 825 pipe, Incoloy 825 tube/tubing and Incoloy 825 plate.

Chemical Analysis
C	.05 max
MN	1.0 max
S	.03 max
Si	.5 max
Cr	19.5- 23.5
Ni	38.0- 46.0
Mo	2.5- 3.5
Cu	1.5- 3.0
Ti	0.6- 1.2
Al	0.2 max
Fe	22.0 min

Incoloy 825 Material Advantages

UNS N08825 is designed to provide exceptional resistance to many corrosive environments. It is like alloy 800 but has improved resistance to aqueous corrosion. It also maintains excellent resistance to both reducing and oxidizing acids, to stress-corrosion cracking, and to localized attack such as pitting and crevice corrosion. Some of the additional benefits associated with Alloy 825, include:

Good mechanical properties at both room and elevated temperatures up to approximately 1000°F
Permission for pressure-vessel use at wall temperatures up to 800°F
Excellent resistance to reducing and oxidizing acids
Good resistance to stress-corrosion cracking
Satisfactory resistance to localized attack like pitting and crevice corrosion
Very resistant to sulfuric and phosphoric acids

Incoloy 825® Available Formats

Incoloy 825® sheet is available in thicknesses ranging from .020 to .156". Incoloy 825® strip in coil form is available in lighter gauges up 12" wide. Incoloy 825® plate is available up 3" thick.
Nickel alloy Incoloy 825® bar is available in wrought bar up to 6" diameter and larger sizes and shapes may be forged to order.
Incoloy 825® seamless pipe is available up to 8" NB. Larger sizes are available in welded construction (100% X-ray) and can also be fabricated to order. Incoloy 825® tubes are available up to 1-1/2" OD. Nickel alloy Incoloy 825 nickel alloy redrawn tubes and tubing with tight tolerances can be supplied in almost any size no matter how small the size or quantity. Additionally, Magellan Metals offers nickel alloy Incoloy 825® in a variety of forms, including:

Bar
Wire
Sheet
Plate
Forgings
Pipe fittings
Flanges
Seamless & Welded pipe
Seamless Tube & Welded tube
Weld Rod

Incoloy Alloy 825 Applications

Nickel alloy UNS N08825 has many different industrial applications, some of which include:

Propeller shafts
Phosphoric acid evaporators
Tank trucks
Hot vessels for food, water, sea water
Sulphuric acid piping and vessels
Marine exhaust systems
