C - 912D - 365 - 192 API Carbon Steel Beam Pumping Unit For Petroleum Production

Pumping unit is the main ground equipment in the pumping system of pumping unit deep well pump. The beam pumping unit is mainly composed of beam - connecting rod - crank mechanism, reducer, power equipment and auxiliary equipment. During operation, the power machine transmits the high-speed rotation to the crank shaft through the belt and reduction gearbox, and drives the crank shaft to rotate at low speed. The crank drives the traveling beam to swing up and down through the beam through the connecting rod. The rope hanger hung on the donkey head drives the sucker rod to move up and down.

According to the structure, beam pumping units are mainly divided into two categories: ordinary beam pumping units and front mounted beam pumping units.

With the continuous development and progress of pumping unit manufacturing technology, since the 1990s, different forms of energy-saving pumping units have been developed. Energy saving pumping units still belong to the structure of ordinary beam pumping units. The structural characteristics of energy-saving pumping units will be introduced in energy-saving technology.

The main components of the ordinary beam pumping unit and the front beam pumping unit are the same, but the connection position between the beam and the connecting rod is different. Ordinary pumping units generally use mechanical balance, while the front-end pumping units mostly used pneumatic balance at first, but due to the imperfection of technology, the method of mechanical balance was used later. At present, the front-end pumping units used in our factory are all mechanical balance. The crank angle of up stroke and down stroke of the front mounted pumping unit is 195 ° and 165 °, making the up stroke slower than the down stroke.

how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

what can you buy from us?
Drilling and Completion Equipment,Nitrogen Generation Equipment,Oil Stimulation Equipment,Wellhead and Well Control Equipment,Natural Gas Compression Equipment,Artificial Lift Oil Extraction Equipment,Pumps,Pipes

what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

Puyang Zhongshi Group Co., Ltd., restructured from SINOPEC in 1997 has 20 years experience on manufacturing petroleum machinery products . The company registered capital is 10 million U.S. dollars, with annual export 30 million U.S. Dollars.

We have competitive price of our main products like: subsurface sucker rod pump, pumping unit, cementing tools, wellhead (Christmas Tree), etc, with certificates of API11AX,API11E,API6A,API5CT,ISO14001 and ISO9001 approved. We have 9 factories, 580 employees, including more than 160 technicians and engineers.

With 20 years manufacturing experience and more than 10 years exporting experience, our main clients include all oilfields in China such as: Zhongyuan, Daqing, Shengli, Changqing, Nanyang, Karamay, etc and we have exported to more than 30 countries abroad such as: Indonesia, Thailand, Myanmar, Russia, Kazakhstan, Venezuela, Peru, Columbia, Canada, America, Sudan, Egypt, Iran, Australia etc.

We would like to cooperate with friends from all over the world with high quality products and service to achieve mutual development .
