3.2mm Dual Wall Heat Shrink Tube Polyolefin Black 1mm

    Buy cheap 3.2mm Dual Wall Heat Shrink Tube Polyolefin Black 1mm from wholesalers

    Buy cheap 3.2mm Dual Wall Heat Shrink Tube Polyolefin Black 1mm from wholesalers
    • Buy cheap 3.2mm Dual Wall Heat Shrink Tube Polyolefin Black 1mm from wholesalers
    • Buy cheap 3.2mm Dual Wall Heat Shrink Tube Polyolefin Black 1mm from wholesalers

    3.2mm Dual Wall Heat Shrink Tube Polyolefin Black 1mm

    Ask Lasest Price
    Brand Name : Long
    Model Number : SBRS-(3X,4X)GF
    Certification : ISO
    Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram
    Supply Ability : 400000meters per day
    Delivery Time : 1-9days
    • Product Details
    • Company Profile

    3.2mm Dual Wall Heat Shrink Tube Polyolefin Black 1mm

    1/8 3.2mm Black Dual Wall Adhesive Lined Cross-Linked Polyolefin Tubing


    Adhesive lined heat shrink tubing ideal for applications where both exceptional flame retardancy and environmental sealing capabilities are required.


    Features


    3:1&4:1 shrink ratio

    Highly flame retardant

    Superior sealing against water, moisture or other contaminants

    High shrink ratio allows for coverage of irregularly shaped connectors and components

    Superior sealing against water, moisture and other contaminants

    Continuous operating temperature:-55°C-135°C

    Fully shrink temperature:^125°C

    Meets MIL-DTL-23053/4


    Dimensions

    SBRS-(3X)GF

    SizeExpandedAfter RecoveryStandard Package
    InchmmInternal Diameter mmInternal Diameter mmTotal Wall Thickness mmAdhesive Thickness mmSpool Lenath M/spooF
    1/83.23.21.00.90±0.300.40±0.20200
    3/164.84.81.61.05±0.300.40±0.20100
    1/45.45.42.21.25±0.300.45±0.20100
    5/167.97.92.71.35±0.300.45±0.20100
    3/89.59.53.21.45±0.300.50±0.2050
    1/212.712.74.21.650±0.300.50±0.201.22OR25M/Roll
    5/815155.21.80±0.300.55±0.301.22OR25M/Roll
    3/419.119.16.31.95±0.300.60±0.301.22OR25M/R0II
    125.425.48.52.00±0.400.60±0.301.22OR25M/R0II
    1-1/4303010.22.15±0.400.65±0.301.22OR25M/Roll
    1-1/2393913.52.45±0.400.75±0.301.22OR25M/Roll
    2505017.02.75±0.400.80±0.301.22OR25M/Roll

    SBRS-(4X)GF


    SizeExpandedAfter RecoveryStandard Package
    InchmmInternal Diameter mmInternal Diameter mmTotal Wall Thickness mm

    Adhesive

    Thickness mm

    Spool Length M/spool
    5/324.04,01.01.05±0.300.50±0.20200
    1/46.06,01.51.15±0.300.50±0.20100
    5/168.08,02.01.55±0.300.60±0.2550
    1/212.012,03.01.75±0.300.60±0.251.22OR25M/R0II
    5/816.016,04.02.00±0.350.70±0.301.22OR25M/Roll
    25/3220.020,05.02.30±0.400.70±0.301.22OR25M/Roll
    124.024,06.02.60±0.400.75±0.301.22OR25M/Roll
    1-1/432.032,08.03.00±0.500.90±0.301.22OR25M/Roll
    252.052,013.03.35±0.500.95±0.301.22OR25M/Roll



    Technical Data


    Tensile Strength(MPa)ASTM D2671m1212.5
    Elongation(%)ASTM D2671XOO450
    Tensile Strength after aging (MPa)MIL-DTL-23053/4N8.48.5
    Elongation after aging(%)MIL-DTL-23053/4^100350
    Dieletric strength(kv/mm)IEC 60243M1517.5
    Volume resistivity(Q.cm)IEC 600933s1X10142.5X1014
