| Model Number: | G535 |
| Product Size: | 1600*1500*2310mm |
| Pass Width: | <=600mm |
| Frequency: | 50Hz |
| Thickness: | 1.2mm/1.5mm |
| Material: | SUS304 |
| Communication Interface: | RS458, Dry Contact |
| Infrared Sensor: | NA |
| Throughput rate: | 35p/m |
| Power Supply: | 100-240V(AC) |
| Operational Voltage: | 24V(DC) |
| Max Power Consumption: | 30w |
Dimension Diagram
Features And Benefits:
1. Running stable without noise and mechanical impact
2. The passing person number of the persons can be set
3. Several ways of working molds for you to choose
4. Bi-direction, or one direction permitted, one forbidden, or one
direction charged,one for free, and all the working molds set by
the buttons in the main control board
5. Beam falling and lifting can be controlled in far distance so to
satisfy the special requirement of the users and the request of
fire protection.
6. Direction-guide lights in the turnstile to tell you whether the
direction to go or not
7. The standard electrical interface connected with various kinds
of reader and writer equipment, RS485 Communication interface,
Relay interface, Level interface
8. All the functions realized in one integration machine and
controlled and managed by the computer in the far distance
9. The number of the persons passed by can be counted automatically
which can also be displayed in LED
10. Beam can be lifted and fall when power is cut-off, arms auto
rise up when power on and auto stop on obstacle
11. The function with or without card-reading memory can be set
according to your demand.
12. Self-check and alarm for coinventing to operate
Project Case
Service And Shipping
FAQ:
1. How about your company’s actual strength?
We are the top 3 in turnstile field in China. We have more than 100
employees, a R&D group with 20 people, 1 office and 3
factories. Factories and office buildings are 5000 square meters in
total.
2. Shall we do promissory note settlement?
We can accept confirmation, irreversible promissory note of 15 days
at most.
3. How about the lead time?
Normally we have stock for the hot sale models of standard
products.
Generally standard products need 10 working days.
The customized products need 20 working days.
4. How long is your warranty period?
13 months, add 10% of contract amounts since the second year,15% of
the contract amounts since the third year.
5. How about your package?
Exported product: Wooden case package of Export exempted from
inspection plus pearl wool and plastic wrap
Domestic: Bubble wrap plus carton or pearl wool plus wooden
packaging.
