HZFS-031 500lbs Mini Stainless Steel disk Weighing Load Cell Weight Force Sensor IP67 With 4 Inner Threads 5VDC

    Buy cheap HZFS-031 500lbs Mini Stainless Steel disk Weighing Load Cell Weight Force Sensor IP67 With 4 Inner Threads 5VDC from wholesalers

    Buy cheap HZFS-031 500lbs Mini Stainless Steel disk Weighing Load Cell Weight Force Sensor IP67 With 4 Inner Threads 5VDC from wholesalers
    • Buy cheap HZFS-031 500lbs Mini Stainless Steel disk Weighing Load Cell Weight Force Sensor IP67 With 4 Inner Threads 5VDC from wholesalers

    HZFS-031 500lbs Mini Stainless Steel disk Weighing Load Cell Weight Force Sensor IP67 With 4 Inner Threads 5VDC

    Ask Lasest Price
    Brand Name : Innovation
    Model Number : HZFS-031
    Payment Terms : L/C, D/P, T/T, Western Union
    Supply Ability : 1000pcs per month
    • Product Details
    • Company Profile

    HZFS-031 500lbs Mini Stainless Steel disk Weighing Load Cell Weight Force Sensor IP67 With 4 Inner Threads 5VDC

    Pressure Testing For Small Space Load Cell


    500lbs Stainless Steel Pressure Testing For Small Space Mini Load Cell IP67 with 4 inner threads


    Detailed Product Description

    Rated capacities(Emax): 50, 100, 250, 500lb

    Recommended Excitation: 5V DC

    Material: Stainless Steel



    ItemsUNITTECHNICAL DATA
    Rated capacities(Emax)lb50, 100, 250, 500
    SensitivitymV/V0.3~2.0
    Total errorF.S±5%
    Creep error(30min)F.S±0.5%
    Zero balanceF.S±1%
    TCOF.S/℃±0.5% / 10
    TC SPANF.S/℃±0.5% / 10
    Input impedanceΩ350±20
    Output impedanceΩ352±3
    Insulation impedance≥5000
    Temperature range, compensated-10 ~ +40
    Temperature range, operating-30 ~ +70
    Maximum safe overloadF.S120%
    Ultimate overloadF.S150%
    Excitation, recommendV5V DC
    Excitation, maximumV5V DC
    Protection classIP67
    ConstructionStainless Steel
    CablemLength: 1
    mmDiameter: φ3
    WiringExc+(Red) Exc-(Black) Sig+(Green) Sig-(White)
