3.5" Lcd Tft Touch Screen 320x240 Lcd Display With PCB Driver Board
1. Specification of 3.5 inch tft lcd touch screen
| Module number | CH350QV12A-CT-PA |
| Resolution | 320*240 dot |
| Active Area | 70.08*52.56 mm |
| View angle | 80/80/80/80 |
| Pixel Arrangement | RGB-stripe |
| Surface Treatment | Plant |
| Electrical Interface | LVDS |
2. Description of lcd touch display
CH350QV12A-CT is a 3.5” capacitive touch Screen Display Module,
including a small tft lcd panel, a control IC, a CTP, a backlight
and an FPC. This Model adopts IPS/Transmissive/Negative display
mode and has all Viewing Direction. The control IC is mounted on
the glass and can be interconnected with other display components
through the FPC. The Capacitive touch panel adopts the I2C
interface and can be removed or replaced with a resistive touch
panel. The FPC can be redesigned according to customer
requirements, Including shape structure, interface definition, etc.
In addition, we also have a lot of technical accumulation in
integrating Tft Lcd Module into project components with touch and
cover, which is of great significance for providing customers with
personalized customization services.
3. Drawings of touch screen panels
Notes:
(1) Display Type : 3.5 inch TFT+CTP
(2) Viewing Direction : 80/80/80/80
(3) Polarizer Mode : TRANSMISSIVE/NEGATIVE
(4) Operating Temp : -20~70 ℃
(5) Storage Temp : -30~80 ℃
(6) Unmarker Tolerance: ±0.20
(7) Protection : ROHS
