MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits

    Buy cheap MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits from wholesalers

    Buy cheap MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits from wholesalers
    • Buy cheap MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits from wholesalers
    • Buy cheap MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits from wholesalers
    • Buy cheap MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits from wholesalers

    MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits

    Ask Lasest Price
    Brand Name : HENGXIANG
    Model Number : MPN55
    Certification : CE,ISO9001
    Price : negotiable
    Payment Terms : D/A, D/P, T/T, Western Union, Credit Card, Master Card,Paypal, etc
    Supply Ability : 100K pieces per year
    Delivery Time : 3-5 working days for sample order, 7-15 working days for mass order
    • Product Details
    • Company Profile

    MPN55 Multi Turn Hollow Shaft Absolute Encoder Parallel 24 Bits

    absolute patallel encoder micr encoder MPN55 single-turn multi-turn 24 Bits Absolute encoder

    ★Overview
    Quick Details
    Model Number:
    Absolute type
    Type:
    ABSOLUTE ENCODER
    Place of Origin:
    Shanghai, China
    Brand Name:
    HENGXIANG
    Usage:
    Optical encoder
    Theory:
    Optical encoder
    Output:
    Other
    Description:
    MPN55 encoder
    Brand:
    HENGXIANG
    Encoder type:
    Absolute encoder
    External diameter/Thickness:
    55mm/15mm
    Hollow shaft type:
    Though hole
    Hollow shaft diameter:
    14/15/19/20/24mm
    Resolution:
    single-turn:17-24Bits;multi-turn: 1716-2416bits
    Electrical connection:
    Radial socket/cable
    Protection:
    IP50
    Net weight:
    About 150g
    Supply Ability
    Supply Ability
    10000 Piece/Pieces per Month
    Packaging & Delivery
    Packaging Details
    package for MPN55
    Port
    Shanghai
    Video Description
    00:00
    00:45
    Product Description

    • About MPN55 absolute encoder


    -- RS485/SSI/Biss-C signal
    --Single-turn and multi-turn
    --Extra thin 15mm
    --Machanical flexible connection design
    --Especially designed for limiting installtion spaces
    -Clamping flange;    Housing: Ø 65 mm
    --17/24-bit Single-turn/Multi-turn;
    --Through hollow shaft up to ø24 mm
    Encoder multiturn / RS485/SSI/Biss-C
    -Resolution: singleturn 24 bit, multiturn 24+16bit

    MPN55 Series Rotary encoder Parameters
    Items
    Basic parameters
    Brand
    Hengxiang
    Encoder type
    Absolute encoder
    External diameter
    55mm(Mounting flange 65mm)
    Thickness
    15mm
    Hollow shaft type
    Through hole
    Hollow shaft diameter
    14mm; 15mm; 19mm; 20mm; 24mm
    Resolution
    single-turn:17Bit, 19Bit,20Bit, 22Bit, 24Bit
    multi-turn: 1716=17+16Bit, 1916=19+16Bit,
    2016=20+16Bit, 2216=22+16Bit,2416=24+16Bit
    Interface
    E=SM08B-GHS-TB ；J=radial cable
    Communication
    B=BISS-C; S=SSI
    Electrical connection
    R=RS-485
    Output mode
    M=multi-turn
    S=single-turn
    Scanning principle
    Reflective grating code
    Accuracy
    ±80"
    Response speed
    Normal action: 6000min-1
    RMS position signal noise
    ±2@18 bits/r
    Communication clock frequency
    ≤10MHz(BISS) or ≤ 5MHz(SSI)
    Starting time
    typical value: 13ms
    Absolute position sampling period
    ≤75 ns
    Allowable speed
    ≤32200 r/min (restricted by mechanical speed limit)
    Cable
    Differential twisted-paired cable
    Cable length
    200mm-10000mm
    Mechanical Connection
    With bearing& encircled locking shaft
    Starting Torque
    less than 9.8×10-3 N.m
    Inertial moment
    less than 6.5×10-6 kg.m2
    Shaft load
    Radial 30N; Axial 20N
    Slew speed
    ≤6000rpm
    Shell Material
    Aluminum
    Environmental temperature
    Operating: -20~+95℃; Storage: -25~+100℃
    Environmental humidity
    Operating and storage: 35~85%RH(Noncondensing)
    Vibration
    Amplitude 1.52mm, 5~55HZ,2h for X,Y,Z direction individually
    Shock
    980m/s2 11ms, three times for X,Y,Z direction individually
    Protection
    IP50
    Net weight
    About 150g
