Production steel category
301/304/316/409L/410L/430/316L/304L/409/310S/321
200 series: 201,202,202Cu,204Cu,
300 series:
301,303/Cu,304/L/H,304Cu,305,309/S,310/S,316/L/H/Ti,321/H,347/H,330,
400 series: 409/L,410,416/F,420/F,430,431,440C,441,444,446,
600 series: 13-8ph,15-5ph,17-4ph,17-7ph(630,631),660A/B/C/D,
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS
S32760,2304,LDX2101.LDX2404,LDX4404,904L
Others: 254SMo,253Ma,F15,Invar36,1J22,N4,N6 etc
304 stainless steel capillary is a high performance alloy steel
tube, excellent 304 stainless steel capillary can resist the
corrosion of air or various chemical substances, but also has a
smooth surface. However, generally speaking, 304 stainless steel
capillary mainly as a variety of wire and cable protection tube
support structure.
Chemical composition%:
| C | Si | Mn | Cr | Ni | S | P |
| ≤0.07 | ≤1.0 | ≤2.0 | 17.00~19.0 | 8.00~11.0 | ≤0.03 | ≤0.035 |
The physical characteristics
| GB brand | The use of temperature | Magnetism |
| OCr18Ni9 | -196℃~800℃ | no magnetism |
Features:
1.Good softness, corrosion resistance, high temperature resistance,
abrasion resistance, tensile strength, water resistance and
excellent electromagnetic shielding performance.
2.It is suitable for flattening, flaring, stretching, bending and
so on
3.Stainless steel threading hose between the side buckle has a
certain tension, to prevent hose damage due to hose damage. Axial
tension can withstand more than 6 times of nominal inner diameter.
4.The stainless steel capillary tube is easy to install, and the
low-efficiency energy can be used effectively to achieve
energy-saving and comfortable effect.
Application:
Capillary mainly used with automatic instrument signal tube,
automatic instrument wire protection tube; Precision optical ruler
circuit, industrial sensors, electronic equipment circuit
protection tube; Safety protection of electrical circuit, capillary
protection of thermal instrument and inner support of hollow high
voltage optical cable.
Stainless steel capillary: pen tube, core tube, electronics,
electrical appliances, lamps and lanterns, clock accessories
Stainless steel precision capillary: medical instruments, needles,
fluids, high-pressure airflow, and so on
Stainless steel tube: decoration, decoration, transportation,
jewelry products.
Production capacity
Chemical composition(JIS-G4305/4312) Unit:%
| Steel category | C | Si | Mn | P | S | Cr | Ni | Mo | Ti |
| 301 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 16.00-18.00 | 6.00-8.00 | | |
| 304 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 18.00-20.00 | 8.00-10.50 | | |
| 316 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 16.00-18.00 | 10.00-14.00 | 2-3 | |
| 409L | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 10.50-11.75 | | | 6*C%-0.75 |
| 410L | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 11.00-13.50 | | | |
| 430 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 16.00-18.00 | | | |
| 316L | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 16.00-18.00 | | | |
| 304L | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 18.00-20.00 | 12.00-15.00 | 2-3 | |
| 409 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 10.50-11.75 | 9.00-13.00 | | 6*C%-0.75 |
| 310S | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 24.00-26.00 | 19.00-22.00 | | |
| 321 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | 17.00-19.00 | 9.00-13.00 | | ≥5*C% |
| Item | Stainless steel sheet / stainless steel plate /stainless steel coil |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,BS,GB |
| Material | 201,202,304,304L,309S,310S,316,316L,316Ti,317L,321,347H,
409,409L,410,420,430 |
| Finish(Surface) | NO.1, NO.2D, NO.2B, BA,NO.3, NO.4,NO.240,NO.400,Hairline,
NO.8,Brushed |
| Exported Area | USA,UAE,Europe,Asia,Middle East,Africa,South America |
| Thickness | Form 0.2-120mm |
| Width | 1500mm/1800mm/2000mm,etc or we can also help cut as you require |
| Length | 6000mm-8000mm or we
can make the length as you require |
| Package Details | Standard seaworthy package(wooden boxes package,pvc package,
and other package)
Each sheet will be covered with PVC, then put into wooden case |
| Payment | Payment by T/T, 30% as advance payment and 70% balance pay before
shipping. |
| Advantage |
1.Alaways have stock
2.bottom price
3.High quality,quantity is with preferential treatment
4.We can cut stainless steel sheet in any shapes
5.Strong ability to supply
6.Famous stainless steel company in China and overseas.
7.Branded stainless steel
8.Reliable quality and service
|
