    Q235 Electrical Steel Tubular Pole Galvanized Power Overhead Project

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP-110KV
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO / drawing / prepayment confirmed
    • Product Details
    • Company Profile

    Q235 Electrical Steel Tubular Pole Galvanized Power Overhead Project

    Galvanized Power Transmission Line Overhead Project Q235 electrical Steel Tubular Pole

    Product Description:


    Products
    • Electrical Power Pole Power Transmission Poles Power Transmission Line For Electrical Power Transformer Substation​

    Application
    • Electrical Power Transformer Substation

    Standrad
    • NEA Standard

    Painting
    • According to clients' request

    Shape
    • Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc),Tubular, Tapered

    Galvanization
    • Hot dip galvanization of substation structure is in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
    Joint
    • Joint with flange mode.

    Product Advantages:

    A. Management team: We have a professional design team to provide services for customers. Provide design drawings.

    B. ISO 9001:2008 certificate provided .

    C. QC Inspection: We have an inspector team to inspect the whole production line, and each pole should be inspected in accordance with the drawing, to make sure all poles are passed before delivery.

    Process:

    1.Raw materialtest :When purchasing the raw material(steel plate ),on sheet of mill certificate from mill factory must be enclosed.When the raw material arrives at the warehouse ,the quality department must take the elongation test and the chemical composition analysis to make sure the raw material have meet all the standard that the needed before production.
    Material standard :ASTM GR65
    2.Cuting :Cuting the raw material that have meet all the standard required into different length and width .

    3.Molding :Forming the cutted steel plate into the shape (circular or polygonal)that as per specified in the drawing .
    4.Welding :After molding ,weld the steel plate together .Uauslly it is longitudinal welds.
    5.Dimension verify :Afer welding ,check the diameter ,length according to the drawing .
    6.Flange:Weld the flange into the main pole
    Welding standard:ASTM A 252-1998 or ASTM A 714-1999
    7.Drill:Drill the hole at the right location as requested in the drawing.
    8.Calibration:check the straightness and diameter to make sure it meet all the requirement .
    9.Deburr: All burrs after drilling or cutting of steels shall be deburred and appropriately chamfered before galvanized
    10.Galvanization :All poles internally and externally are to be hot-dip galvanized in accordance with requirement mentioned in the relevant drawing or specification
    Galvanization standard:IS2629-1985 ,BS729-1971
    11.Recalibration:recheck the straightness and diameter to make sure it meet all the requirement after galvanization.
    12.Thread:Thread the parts that needs screw thread ot make sure it can installed successfully at site .
    13.Packages: Our poles as normal cover by sea /road -worthy wooden packing material ,anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data


    Our seivices:

    1. Reply your inquiry in 24 working hours.

    2. Experienced staffs answer all your questions in fluent English.

    3. Customized design is available. UEM&UBM are welcomed.

    4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.

    5. Special discount and protection of sales are provided to our distributor.

    6. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.

    7 Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.

    8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.


    Contact Us:

    Jiangsu Hongguang Steel Pole Co., Ltd.

    Address: Wanshi Industrial Zone, Yixing City, Jiangsu Pro., P.R.China, 214212

    Telphone: +86 510 878 441 56

    Fax: +86 510 878 435 28

    Whatsapp:+86 18706156685

    Company youtube link: https://youtu.be/C9sHcnm3RKI


    Please feel free to contact us!
