Steel Grade: QStE420TM | Material No: 1.0980
We offer guidance on steel equivalent grades and hard to find steel
specifications.
CHEMICAL COMPOSITION(QStE420TM):
C(％):0.12
Si(％) : 0.50④
Mn(％) : 1.6
P(％)≤:0.025
S(％)≤: 0.015
Ti(％)≤:0.15
V(％):0.2
Other(％):Al≤0.015％, Nb≤0.09％ | MECHANICAL PROPERTIES(QStE420TM):
Tensile Strength σb(T)/Mpa:480～620
Yield Strength σs(T)/MPa≥:420
Extensibility δ5(T)(%)≥:21
Ballistic AKV/J(-20℃)≥:28
Flexural Center Dia Cold-bend Test(180℃/T) :d=0.5a
Annealing/℃⑨ :530～580
Normalizing/℃⑩ :— |
Remark(QStE420TM):
①, The European standard is come out from EN 10194-1995.
②, The steel should be added enough Al, Nb, Ti, V and fine grain in
order to solidify N.
③, When the thickness is exceed 4mm, the composition of C is lower
than ≤0.12％.
④, The upper limit of Mn composition can be more than 0.50％.
⑤, The upper limit of Mn composition can be more than 0.40％.
⑥, The upper limit of Mn composition can be more than 0.30％.
⑦, The V+Nb+Ti should be lower than 0.22％.
⑧, d-->Flexural Center Dia, a--> thickness of test of sample.
⑨, The time of heat preservation is 30min.
⑩,The time of heat preservation should be 2min/mm.
We are always interested in hearing from you-Questions, Comments or
Orders-Let us know what you think.
Introduction Structural Steel(QStE420TM)
Structural steel is mainly used in the manufacture of engineering
components and machine parts, such as using steel .
Classification(QStE420TM)
Steel construction: to build the boiler, ships, Bridges, factories
and other steel used in construction, this kind of steel, usually
after welding construction, so generally no more than 0.25% carbon,
low carbon steel, mostly used in the condition of hot rolling or
normalizing. Mechanical steel: steel used in the manufacture of
machines or mechanical parts, this kind of steel carburizing often
passes or quenched and tempered treatment before use.Used to deal
with the carburizing steel is refers to the carbon content in 0.1%
~ 0.3% of low carbon steel.Used to deal with the quenched and
tempered steel, is refers to the carbon content in 0.3% ~ 0.3% of
medium carbon steel.Mechanical steel include spring steel and
bearing steel, however, because the carbon content is higher, have
special USES, so often separate it into a class.
Application of Structural Steel(QStE420TM)
Building bar; Agricultural machinery; Shipbuilding steel; Boiler
steel; The compressor crankshaft, connecting rod, piston rod, etc.
Bearing steel; Bolts, nuts, washers, Gear parts; Railway vehicle;
The oil derrick; Pressure vessel; The boiler steam drum; Factory
building structure; Rolling stock; Oil tank, oil tank; Automobile
vertical and horizontal beam; High pressure blower blade; Turbine,
worm; The important parts; Spiral spring, leaf-spring, etc
