factory 0.5in Titanium BW cap Fitting Gr2 Gr7 For Pressure Vessel
A fitting welded to the pipe head or fitted to the outer thread of
the pipe end to cover the pipe. Used to close the pipe, the effect
is the same as pipe blocking. According to the shape of the head
surface, it can be divided into convex shape, conical shape, flat
shape and combination shape
Application :The BW cap use of titanium head Head is an indispensable and
important part of pressure vessel equipment in petrochemical,
atomic energy and food and pharmaceutical industries. The head is
the end cover of the pressure vessel, which is a main bearing part
of the pressure vessel. Its role is to seal
Surface Smoothness :Clean, dust-free
Testing: mechanical properties, chemical composition and ultrasonic
detection
DN
| Outside diameter of groove d | e | Thickness | e1 |
| I | II |
| 15 | 21.3 | 18 | 25 | 4.57 | 25 |
| 20 | 26.9 | 25 | 25 | 3.81 | 25 |
| 25 | 33.7 | 32 | 38 | 4.57 | 38 |
| 32 | 42.4 | 38 | 38 | 4.83 | 38 |
| 40 | 48.3 | 45 | 38 | 5.08 | 38 |
| 50 | 60.3 | 57 | 38 | 5.59 | 44 |
| 65 | 76.1(73) | 76 | 38 | 7.11 | 51 |
| 80 | 88.9 | 89 | 51 | 7.62 | 64 |
| 90 | 101.9 | - | 64 | 8.13 | 76 |
| 100 | 114.3 | 108 | 64 | 8.64 | 76 |
| 125 | 139.7 | 133 | 76 | 9.65 | 89 |
| 150 | 168.3 | 159 | 89 | 10.92 | 102 |
| 200 | 219.1 | 219 | 102 | 12.70 | 127 |
| 250 | 273.0 | 273 | 127 | 12.70 | 152 |
| 300 | 323.9 | 325 | 152 | 12.70 | 178 |
| 350 | 355.6 | 377 | 165 | 12.70 | 191 |
| 400 | 406.4 | 426 | 178 | 12.70 | 203 |
| 450 | 457.0 | 478 | 203 | 12.70 | 229 |
| 500 | 508.0 | 529 | 229 | 12.70 | 254 |
| 550 | 559 | - | 254 | 12.70 | 254 |
| 600 | 610 | 630 | 267 | 12.70 | 305 |
| 650 | 660 | - | 267 | - | - |
| 700 | 711 | 720 | 267 | - | - |
| 750 | 762 | - | 267 | - | - |
| 800 | 813 | 820 | 267 | - | - |
| 850 | 864 | - | 267 | - | - |
| 900 | 914 | 920 | 267 | - | - |
| 950 | 965 | - | 305 | - | - |
| 1000 | 1016 | 1020 | 305 | - | - |
| 1050 | 1067 | - | 343 | - | - |
| 1100 | 1118 | 1120 | 343 | - | - |
| 1150 | 1168 | - | 343 | - | - |
| 1200 | 1219 | 1220 | 343 | - | - |
FAQ
1. Are you the manufacturing or trading company?
Real manufacturing company, started from 2001, nearly 20 years.
With 2 sales teams for foreign trading business, started from 2008,
more than 10 years experiences.
2. Do you have a dedicated R & D team? Can you design a product for
us?
We have a dedicated technical team responsible for research and
development. But most of titanium fittings are standard, we can
follow ASTM or other you asked.
3. Can you provide samples? Is there a charge?
Samples can be provided for a fee.
4. What is your payment method?
We can accept T / T, LC, trade assurance order from alibaba.com.
Samples are 100% prepaid. Orders for mass production are below 1000
USD, 100% prepaid, above 1000 USD, 30% prepaid, and 70% paid before
delivery.
5. How long is your delivery time?
Inventory samples: within 3 working days Products for bulk orders:
25-30 days under normal circumstances.
6. After-sales products, how to deal with problems?
Based on our statistics for each year, the probability of problems
with titanium products is around 0.8%. There are two main reasons
for the problem:
1) Among the products that have problems, 93% are misplaced in
pre-sales communication, and the product that the customer needs is
not really clear.
2) 5% is an unexpected situation and the extension of the
construction period.
3) 2% is the problem of transportation and packaging. During
long-distance transportation, the packaging is damaged and the
surface is damaged.
7. What is your company's response to the product in question?
1) Verify and blame for pre-sales communication issues.
Compensation is handled according to the proportion of liability.
2) We are 100% responsible for problems caused by damaged packaging
during transportation.
