Radiant Panel Flame Spread Test Apparatus Surface Flammability
Tester
Description:
This Radiant Panel Flame Spread Test Apparatus is used to measure
and describe the
response of materials, products, or assemblies to heat and flame
under controlled conditions,
but does not by itself incorporate all factors required for
fire-hazard or fire-risk assessment of
materials, products, or assemblies under actual fire conditions.
This machine provides a laboratory procedure for measuring and
comparing surface flammability
of materials when exposed to a prescribed level of radiant heat
energy.
Surface flammability is measured by using a vertically mounted
propane gas and air fueled
radiant heat energy source and a 6 inch by 18 inch test specimen.
The Radiant Panel Flame Spread Apparatus measures the surface
flammability of building
products (ASTM E162) and cellular plastics (ASTM D3675) by using a
gas-fired radiant heat
panel. The test result is an index that is determined from the
flame spread and heat evolution
factors. This index is required in various specifications
especially for the mass transit industry
(buses and trains).
Standard:
ASTM E 162: Standard test method for surface flammability of
materials using a radiant heat
energy source.
ASTM D 3675:Standard Test Method for Surface Flammability of
Flexible Cellular Materials
Using A Radiant Heat Energy Source
Features:
1. The Reflector made from cast iron frame, with surface size
305X457mm,working temperature
815℃
2. The filter equipped with a fan to supply air to the reflector
3. Stainless steel pilot burner assembly, make it fire
automatically
4. Calibration burner has 1.8mm hole on 16 different angles, and
along with the center line.
5. To control the surface temperature of the reflector panel, need
to set black panel body
temperature in the range of 180℃to 230℃, accuracy of ±5℃,
6. Use heat-flow meter(foil disk) to measure the heat radiation
condition of radiant panel
(0~100kW/m2)
7. DAQ(Data Acquisition) system could make test automatically
control and measure.
Machine size
|
1,100(W)×900(D)×1,860(H)mm
|
Control box size
|
600(W)×750(D)×1600(H)mm
|
Power
|
AC 220V, 50/60Hz, 15A
|
Weight
|
150kg
|
Manual
|
available
|
Air exhaust
|
Min 15 ㎥/min |
