Introduction of animal feed pellet machine
This 1ton per hour animal feed pellet production line is used to
press raw materials into pellets.The raw mateirals can be
corn,wheat,grain,wheat,etc.The processing is included
crusher-mixer-conveyor-pellet machine-cooler.This small animal feed
pellet production line is widely used in large,medium and small
scale aquaculture,livestock farms and grain feed processing
plants.The small simple animal feed pellet production line has a
simple and light structure, and the production capacity is
500-2000kg, which is convenient for assemble and maintenance and
very practical for small feed factory, farm and home use.
Processing of 1ton per houranimal feed pellet production line
1. Grain grinder and mixer machine
Raw materials enter into the shredder is broken into
granule,crushed particles passing through the mesh into the
crushing chamber and mixing them at the same time.The mixed grain
powder is used to make pellets.
2. Screw conveyor machine
3. Animal feed pellet machine
Chicken feed pellet machine is the main equipment of feed pellet
line. It mainly makes the crushed powder into the pellets.Ring die is granulation is part of the feed pellet machine, when
the feed ingredients into the ring die abrasive, by squeezing out
feed particles. Feed pellet machine configuration, self-protection
system in unstable voltage and overload operation, can effectively
protect the feed pellet machine, balance weight noise reduction
technology also greatly reduces the feed pellet machine work occurs
when sound, greatly improving the acceptance rate of the feed
processing plant. Feed pellet machine using modulator will feed
ingredients to fully cure, played the feed ingredients of
sterilization, the role of starch aging, improve the feed rate of
pellet formation, and reduce the feed pellet machine, abrasive
wear, extend the life of the road of the feed pellet machine.
4. Animal feed pellet cooler machine
Technical parameter of animal feed pellet production line
Machine name | Pictures | Technical parameter |
Grain crusher and mixer machine |
| Size:1750*1250*2700mm crusher Power :11kw mixer power:3kw capacity :1000kg/h machine weight:600kg |
Screw conveyor machine |
| Model:T-219 Length:3-8m Power :3kw Weight:300kg |
Animal feed pellet machine |
| Power:22kw Capacity:1200kg/h Pellet size:2-9mm Dimension(mm):1720*1350*1675mm Weight:650kg |
Cooler machine |
| Model:SKLN1.0 Capacity:1000kg/h Cooler time:>10minutes Cooling material:+3-+5℃ Powder :2.2kw Cooler size : 2165*1400*3110mm |
Raw materials for making animal feed pellet
1. Alfalfa grass
2. All grains like corn, soybean, wheat, barley, soybean cake, rice
husk, etc.
Final pellets of animal feed pellet production line
