Equipment parameters
| Name | Packaging Bottle Curved Printing Testing Equipment | Model | KVIS-SC02 |
| Software algorithm | Deep learning | Voltage | AC220/50HZ |
| Voltage | 200w | Air pressure | Mpa |
| transfer method | Lossless delivery | Detection status | Online real-time detection |
| Detection method | High-speed industrial camera | Number of camera | 1 |
Packaging bottle curved printing testing equipment
The bottle curved surface printing defect detection equipment is
mainly to deal with the appearance of various fashionable elements
in the packaging design concept. The traditional detection
equipment is aimed at curved products and cannot achieve a
comprehensive detection effect. Therefore, the curved surface
printing products need to be Special and technical testing
equipment. In the curved printing of packaging bottles, the
detection of curved printing defects is the focus of most
manufacturers because small errors will affect the evaluation of
the production process and the impression of consumers on the
brand.
Detection principle
By docking the front-end automation mechanism (which can be
directly docked with conveying lines, robotic arms and other
material-arranging mechanisms, the specific implementation method
is to be determined according to the production site), the curved
surface printing samples are stably and orderly transferred to a
specific detection station, and then passed through an industrial
camera.
The captured high-pixel sample image is transmitted to the image
processing software, and the good and bad products are detected and
determined by the AI artificial intelligence algorithm, and the
corresponding pneumatic components are controlled to remove the bad
products, and finally the qualified products are output, and the
back-end conveyor platform of the testing machine It can be
connected to the automatic packaging mechanism.
Equipment overview:
➢ Online high-speed detection, improve detection efficiency and
accuracy, and reduce labor costs.
➢ Accurate identification of high-pixel industrial cameras, the
number of cameras is designed on demand, the accuracy is 0.1mm, and
the speed is 300 pieces/min (can be customized according to testing
needs).
➢ Compatible with testing products of multiple specifications,
saving costs.
➢ Detect and remove defects such as missing characters, missing
patterns, printing offset, blurring, QR code reading, barcode
reading, black spots, color difference, impurities, etc. of curved
printed products.
Product advantages
- AI algorithm: high stability, can adapt to the disturbance of the
environment and background; after training, it can automatically
identify different defect samples.
- Dataization: independent database, save a variety of samples,
analyze defective products, and keep historical records.
- Multi-directional: carry out all-round inspection without dead
angle on the printing area of the product.
- Visualization: real-time display of sample images, running status,
real-time statistical inspection results and defective product
defect classification information.
- High precision: The detection accuracy rate can reach 99.5%.
- Modularity: The detection function can be flexibly increased or
decreased according to the actual needs of customers.
- Easy to operate: The equipment is easy to operate and easy to
maintain.
