Cross Belt Conveyor Sorting Systems ASRS MHS Many Sorting Outlets
Many Sorting Outlets Cross Belt Sorter Conveyor Sorting Systems
ASRS MHS
| Cross belt sorter |
The cross belt sorter is connected by the main drive belt conveyor
and the trolley carrying the small belt conveyor. When the trolley
moves to the specified sorting position, it rotates the belt to
complete the task of sorting out the goods. Because the main drive
belt conveyor crosses the belt conveyor on the "trolley".
|
| Features |
There are many sorting outlets, which can be sorted on the left and
right sides.
|
| Scope of application |
It is suitable for sorting all kinds of small commodities, such as
food, cosmetics, clothing, etc.
|
The cross-belt sorter uses a linear motor and other power to drive
the end-to-end trolley queue to move at high speed along the
circular track. Pieces are introduced into the sorter trolley
through the semi-automatic or fully automatic introduction table,
the code is read by the scanner and the corresponding address is
found in the background system. When the trolley carrying the goods
runs to the designated sorting port position, the trolley belt
rotates smoothly to sort the shipment.
The system has high sorting efficiency and no damage to various
goods. It is suitable for large and medium-sized sorting sites in
e-commerce, clothing, express delivery, and other industries.
It is suitable for large and medium-sized sorting sites that
require extremely high sorting efficiency and many sorting
directions in industries such as e-commerce, food, cosmetics,
clothing, books, and express delivery.
Product advantages
(1) The trolley is directly driven by a high-torque brushless DC
drum, which is easy to install and maintain, and has high
reliability; the chassis of the trolley is finished with cast
aluminum, which has high strength and simple installation.
(2) The introduction table adopts the integrated design of the
overall frame and is driven by the frequency conversion integrated
motor; the factory is about to complete the pre-commissioning, so
the on-site installation is extremely convenient, and the
installation period is short.
(3) Fully adopts the control system architecture based on
industrial Ethernet, has rich diagnostic functions, and supports
remote maintenance and diagnosis of all core equipment.
(4) All parts of the sorting machine, such as the drive of the
whole machine, are designed with redundancy, which has extremely
high reliability and scalability.
(5) Excellent performance, core indicators such as sorting
efficiency, error rate, and code reading rate are comparable to
imported equipment.
