Nvidia Embedded Solutions Developer Tools , Jetson Xavier Nx Developer Kit

Name: Nvidia Embedded Solutions Developer Tools Jetson Xavier Nx Developer Kit
Brand: NVIDIA
Price: 1 USD

Ask Lasest Price
Brand Name :	NVIDIA
Model Number :	Jetson Xavier NX
Price :	contact sales for updated price
Delivery Time :	2 weeks
Payment Terms :	T/T
Supply Ability :	1000+

Add to Cart

Product Details
Company Profile

Nvidia Embedded Solutions Developer Tools , Jetson Xavier Nx Developer Kit

Jetson Xavier NX Developer Kit Nvidia Embedded Solutions

Jetson SUB Mini PC-Black is based on the Jetson Xavier NX module, which delivers up to 21 TOPS, making it ideal for high-performance compute and AI in embedded and edge systems. Big passive heat dissipation design and OLED make it convenient to achieve quiet and dust forbid situations. With the carrier board, heatsink, pre-installed OS and enclosure, you get your Jetson mini PC with the performance of 384 NVIDIA CUDA® Cores, 48 Tensor Cores, 6 Carmel ARM CPUs, and two NVIDIA Deep Learning Accelerators (NVDLA) engines. Combined with over 59.7GB/s of memory bandwidth, video encoded, and decoded, these features make the module of Jetson Mini PC (Jetson Xavier NX) the platform of choice to run multiple modern neural networks in parallel and process high-resolution data from multiple sensors simultaneously.

Compact design for a mini PC with an overall dimension of 205mm x 130mm x 65mm
Powered by the6-core NVIDIA Carmel ARM®v8.2 64-bit CPU 6MB L2 + 4MB L3
384-core NVIDIA Volta™ GPU with 48 Tensor Cores provides 21 TOPS AI performance
Rich peripherals including Dual gigabit ethernet ports, 4 USB 3.0 Type-A ports, and HDMI port
Pre-installed Wifi module and antenna
Pre-installed 256 GB (2.5 inch SATA) SSD
Pre-installed OLED screen showing ports occupation and storage state, customaziation allowance
Big passive heat dissipation with fully-sealing design
Pre-installed NVIDIA official JetPack software

Specifications

	Jetson SUB Mini PC-Blue	Jetson SUB Mini PC-Black	Jetson SUB Mini PC-Silver	Jetson EX1 Mini PC-Ubuntu
Module	NVIDIA JETSON XAVIER NX
AI Performance	21 TOPs(INT8)
OS	JetPack 4.6			Ubuntu 18.04
CPU	6-core 64-bit CPU, NVIDIA Carmel ARMv8.2
GPU	384-core NVIDIA Volta GPU
Memory	8 GB 128-bit LPDDR4x 51.2GB/s
Module Storage	16 GB eMMC 5.1
Carrier Board Storage	128GB M.2 NVME SSD	256GB SATA	128GB M.2 NVME SSD	256GB M.2 NVME SSD
Wifi	Pre-installed M.2 E Wifi	Pre-installed USB 2.0 Wifi	Pre-installed M.2 E Wifi
Power	19V DC	19V DC	19V DC	12V DC
Display	2* HDMI	2* HDMI,	2* HDMI	2* HDMI
Display	2* HDMI	1* OLED screen	2* HDMI	2* HDMI
USB	4* USB3.0(USB 2.0 Integrated),	4*USB3.0(USB 2.0 Integrated),	4*USB3.0(USB 2.0 Integrated),	1*USB3.0(USB 2.0 Integrated),
	1*Micro USB	1*USB Type C	1*Micro USB	1*Micro USB,
				1*USB2.0
Network	1* Gigabit Lan	2* Gigabit Lan*2	1* Gigabit Lan	2* Gigabit Lan
Dimension	130mm x120mm x 50mm	205mm x 130mm x 65mm	130mm x90mm x60mm	134mm x135mm x46mm
Key feature	Blue Aluminum Case;	Whole Black Aluminium Frame;	Whole Silver Aluminium Frame;	Whole Black Aluminium Frame;
	Removable transparent Cover;	Big passive dissipation ;	Portable Oval Size	Narrow space fit,
	Mounting hole design	OLED screen		Multiple software drivers installed
Reference application	Indoor AIoT, Home development, etc.	Industry IoT, Harsh environment applications, etc.	Smart Office, Smart Home, Education, etc.	Industry control, Lab, etc.

Module Technical Specifications
AI Performance	21 TOPS
GPU	384-core NVIDIA Volta™ GPU with 48 Tensor Cores
CPU	6-core NVIDIA Carmel ARM®v8.2 64-bit CPU, 6MB L2 + 4MB L3
Memory	8 GB 128-bit LPDDR4x, 59.7GB/s
Storage	16 GB eMMC 5.1
Power	10 W \| 15 W \| 20W
PCIe	1 x1 (PCIe Gen3) + 1 x4 (PCIe Gen4), total 144 GT/s*
CSI Camera	Up to 6 cameras (24 via virtual channels)
	12 lanes (3x4 or 6x2) MIPI CSI-2
	D-PHY 1.2 (up to 30 Gbps)
Video Encode	2x 4K60 \| 4x 4K30 \| 10x 1080p60 \| 22x 1080p30 (H.265)
	2x 4K60 \| 4x 4K30 \| 10x 1080p60 \| 20x 1080p30 (H.264)
Video Decode	2x 8K30 \| 6x 4K60 \| 12x 4K30 \| 22x 1080p60 \| 44x 1080p30 (H.265)
	2x 4K60 \| 6x 4K30 \| 10x 1080p60 \| 22x 1080p30 (H.264)
Display	2 multi-mode DP 1.4/eDP 1.4/HDMI 2.0
DL Accelerator	2x NVDLA Engines
Vision Accelerator	7-Way VLIW Vision Processor
Networking	10/100/1000 BASE-T Ethernet
Mechanical	69.6 mm x 45 mm
	260-pin SO-DIMM connector

Carrier Board Connector Summary:

Feature	Carrier board for NVIDIA® Jetson™ Nano/NX/TX2 NX
Module Compatibility	NVIDIA® Jetson™ Nano/NX /TX2 NX
PCB Size / Overall Size	170mm x 100mm
Display	2x HDMI
Ethernet	2x Gigabit Ethernet (10/100/1000M)
USB	4x USB 3.0 Type A (Integrated USB 2.0)
USB	1x USB 2.0 Type C(Support OTG)
SATA	Pre-installed 256GB 2.5 inch SATA SSD
USB WIFI Mode	Pre-installed Wifi module (802.11ac and 2.4/5G ITIR mode with support of 433Mbps PHY rate)
CSI Camera	6 x Camera (MIPI CSI-2 )
TF_Card	1 x TF_Card
Audio	1 x Audio Jack,2 x Microphone, 2 x Speaker(1W)
SPI Bus	1 x SPI Bus(+3.3V Level)
FAN	2 x Fan(12V/5V),1 x FAN(5V PWM)
CAN	1 x CAN
Misc.	1 x System Control
	1 x Power Control
	2x I2C Link (+3.3V I/O)
	1 x UART(+3.3V Level)
	2 x GPIO(+3.3V Level)
	2 x SPI Bus(+3.3V Level)
	1 x LED State
Power Requirements	+13V to +19V DC Input @ 8A
Operating Temperature	-25° to +80°
