Applications:
The machine is suitable for packing non sticky, bulk or granular
material, such as medical pills food stuffs, plant seeds, washing
powder, coffee, sugar, desiccant, etc.
Features:
The integrated processes of bag making, measuring, filling,
sealing, cutting, counting and hot pressing codes can be done
automatically.
Packing material:
Several kinds of heat seal lamination, such as PET/plated AL/PE,
PET/PE, PAPER/PE, NYLON, etc.
Film thickness should be less than 8u; while for the film roll, the
internal diameter is 75mm and the external diameter should be
less than 300mm.
Smart Screen
Language: You can choose seven languages, for example:
English,Russian, Spanish, French, etc. You can also customize the
language as needed.
Function: You can set and change the weight of the packaging
material and the length of the bag.
Measuring Type
Name: Metering Pump Device
Material: Food Grade 304 Stainless Steel.
Feature:
1.the machine uses compressed air to control the drive, it is
particularly suitable for use in explosion-proof requirements and
humid environment, a high degree of safety.
2.the use of screw, counter, filling volume adjustment so precise,
in digital form and can be directly reflected;
4. filling fast, filling back and forth 30 times per minute, with
500ml of water, for example, filling accuracy is ± 1%
Bag Maker
*The bag making machine is made of 304 stainless steel and driven
by a servo.
*The packaging film is pulled into the bag making machine by
friction.
*The packaging is simple and beautiful, with a humanized design.
Different bag making equipment can be replaced according to
different bag widths. One machine can pack bags of various widths.
Specifications:
| Power | 4KW | | Material | Stainless steel 304 | | Filling range | 3-150ml | | Bag size | L50-130mm W40-140mm | | Capacity | 30-60bag/m | | Application | Beverage, Chemical, Medical, Food | | Power supply | 220V 50HZ | | Size | 960x670x1700MM | | Weight | 250KG | | Supply Capacity | 50sets/month | | Packing | plywood case |
|
