    DIN2393 Seamless Precision Steel Tube For Heat Exchanger

    Ask Lasest Price
    Brand Name : Joyruns
    Model Number : DIN2393 Gas Spring tube
    Certification : ISO9000
    Price : Negotiable
    Payment Terms : TT OT 100% LC AT SIGHT
    Supply Ability : 1000Ton/month
    Delivery Time : 30DAYS
    • Product Details
    • Company Profile

    DIN2393 Seamless Precision Steel Tube For Heat Exchanger

    DIN2393 ST34.2 Welded Precision Steel Tube for Gas Spring

    DIN 2393 Standard applies to welded precision steel tubes; and in compliance with ISO/DIS 3304.DIN 2393 Precision Welded Steel Tubes is mainly applied for Auto and motorcycle shock absorbers, Gas springs, Hydraulic system steel tubes, Electric industry, Construction machinery, Heat exchanger and Condenser.

    Precision steel tubes
    1. Automotive fields
    A. Fuel injection lines/nozzles
    B. CNG (Compressed Nature Gas) tube-- Burst pressure: 1307Bar, Working Pressure: around 350bar
    C. Drive transmission: Steering column elements
    D. Gear shafts, hand brake, front axles, airbag inflators, stabilizers, seat fasteners, front-wheel driveshafts
    2. Hydraulic Fields
    A. Hydraulic circuits (HPL), pneumatic lines, and hydraulic suspension
    B. Hydraulic cylinders (HPZ)

    Delivery Condition:

    Delivery ConditionSpecification
    BK ( +C )Tubes don't undergo heat treatment following the final cold forming,thus have a rather hig-h resistance to deformation
    BKW ( +LC )The final heat treatment is follwed by cold drawing involving limted deformation. Appopriat-e further processing allows a certain degree of cold droming( eg: handing expanding)
    BKS ( +SR )

    Heat treatment is applied following the last cold forming process, subject to appropriate

    procession conditions, the increate in the residual stresses,involved enables both forming

    and maching to a certain degress.

    GBK ( +A )The last cold forming process followed by annealing in controlled atmosphere.
    NBK (+N )The last cold forming process is followed by annealing above the upper transformation poi-nt in a controlled atmosphere.


    DIN2393 ST34.2 Specifications:

    Grade and Chemical Composition ( )

    Chemical Composition (%, max)
    Steel Grade
    C
    Si
    Mn
    S
    P
    RSt 34-2
    0,15
    0,30
    0,60
    0,025
    0,025
    RSt 37-2
    0,17
    0,30
    0,70
    0,025
    0,025
    St 44-2
    0,21
    0,30
    1,10
    0,025
    0,025


    Mechanical properties

    Steel Grade
    Tensile Strength, N/mm2 (min)
    Предел текучести, N/mm2 (min)
    Elongation, % (min)
    NBK - normalized
    RSt 34-2
    340 - 470
    235
    25
    RSt 37-2
    440 - 570
    255
    21
    St 44-2
    560 - 630
    355
    22
    BK - without heat treatment
    RSt 34-2
    480
    -
    6
    RSt 37-2
    580
    -
    5
    St 44-2
    640
    -
    4
    GBK - annealed
    RSt 34-2
    315
    -
    28
    RSt 37-2
    390
    -
    25
    St 44-2
    490
    -
    21
