    5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine

    Ask Lasest Price
    Brand Name : FECT
    Model Number : PF-450
    Price : USD$ 13,968/ set
    Payment Terms : 30% T/T as deposit in advance, the balance by T/T after production
    Supply Ability : 50 sets per month
    Delivery Time : Within 35 days after deposit received
    • Product Details
    • Company Profile

    5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine

    5-20 bag/min Automatic water cup plastic cup paper cup packing machine


    Advantages

    • The PF450 Paper Cup packing Machine, it can count from 1 to 100(the counting range)of the cups and then pack them.
    • The machine line also been controlled by PLC system and servo motor. And it is very easy to understand and operate.
    • The best advantage is the way of delivery, it is Bele”V”. it can improve the precision of counting and it can make the cups not been worn down.
    • The hole-punching machine has different range of the diameter, customers can choose the needing diameter as they need.
    • The film delivering is under the machine, the thickness of the film with 0.03mm will been no problem.

    Application

    PF450 Paper Cup packing Machine is It used for counting, packing disposable (one-off)cups.

    Packaging:

    Stable wooden package protects machine from strike and damage.
    Wound plastic film keeps machine out of damp and corrosion.
    Fumigation-free package helps the smooth customs clearance.
    The big size machine will be fixed in container without package.

    Quality Guarantee: One year warranty and lifelong technical service, Inspection before delivery is available. The above clause is ONLY effective under the machine is being properly used, any artificial misuse or destroy purposely is not within the limit of Quality Guarantee.

    Installation and Debugging: we can send technician for installation and training at the cost of buyer (visa, round tickets, eating, accommodation in his country and salary 100 USD /day).


    Technical Specification

    TypePF -450 Follow packing machine
    Film max-width450mm
    Film thickness0.02-0.06mm
    Packing speed5-20(bag/min)
    Length200-600mm
    Height≤90mm
    Counting packing machine dimensions3500mm×2050×1350mm
    Power2.8kw
    TypePF 450 Auto counting machine
    Cups diameterΦ60-Φ80mm
    Number of single counting25pcs
    Counting speed200pcs/min
    Way of delivery(choose)6500×1050×1350mm
    Counting packing machine dimensions6500×1050×1350 mm
    Power2.8kw
    Weight1200kg

    Configuration list

    ItemModelQTYBrand
    PLCFP-XU32T1 PCSPANASONIC
    TOUCH SCREENTPC70121 PCSBEIJING KUNLUNTONGTAI
    AIR SWITCHDZ47-63-C105 PCSCHINT
    SWITCHING POWER SUPPLYS-50-241 PCSTAIWAN MINGWEI
    TEMPERATURE CONTROLLERXMTG-90812 PCSZHEJIANG YATAI
    SOLID STATE RELAY220D252 PCSYANGMING, TAIWAN
    FEEDING SERVO / FEEDING SERVOD75AA-10001 PCSINOVANCE
    EMERGENCY STOP SWITCH1 PCSSCHNEIDER
    START SWITCH1 PCSSCHNEIDER
    STOP SWITCH1 PCSSCHNEIDER
    PHOTOELECTRIC SWITCHZ3M-TB221 PCSZHEJIANG JULONG
    COUNTING PHOTOELECTRIC4914 PCSPANASONIC
