herb ginger spice onion drying machine for black pepper and fruit
drying
Brief description:
Brightsail company's hot air circulation drying oven, after several
upgrading, has reached the advanced level at home and abroad. It is
widely used in pharmaceutical, chemical, food, light industry and
heavy industry raw materials and products for heating and
dehumidification.
Basic principle:
The basic principle of BSO series drying oven is that after the
heat source (steam and electricity) is connected, the heat source
heats the heater located in the oven. The heater generates heat
energy to heat the air in the oven, so as to form hot air, so as to
achieve the purpose of drying materials
Main advantages:
1. Strong structure: The drying chamber is made of steel plate, so
the body is very strong.
2. Uniform drying: the hot air flow in the drying chamber is very
uniform.
3. Adjustable working temperature: room temperature to 150 degrees.
4. Adjustable drying time: the time for drying is adjustable.
Technical data:
| Model | BSO-O | BSO-I | BSO-II | BSO-III | BSO-IV |
| Capacity(kg/batch) | 60 | 120 | 240 | 360 | 480 |
| Blower power(kw) | 0.45 | 0.45 | 0.9 | 1.35 | 1.8 |
| Steam expend(kg/h) | 15 | 20 | 40 | 60 | 80 |
| Electric-heating power(kw) | 9 | 15 | 30 | 45 | 60 |
| Down temp(℃) | ±2 | ±2 | ±2 | ±2 | ±2 |
| Tray(piece) | 24 | 48 | 96 | 144 | 192 |
| Overall size(L*W*H)(mm) | 1400*1200*2000 | 1200*2300*2000 | 2300*2200*2000 | 3200*2200*2000 | 4280*2200*2000 |
| Weight(kg) | 820 | 1500 | 1800 | 2200 | 2800 |
Wide application:
After-sales service
1. Technical support for your installation, operation and
maintenance.
2. One year warranty
3. Online support
FAQ:
1) What material you want to dry?
2) What is the water content of your raw material?
3) What the final water content you want to get by dryer?
4) About heat source, you will use electricity or steam?
5) How many kgs do you need for per batch?
6) How many work hours you plan to use per day? (like 8 hours, 10
hours,12 hours...etc)
